SINTERIT LISA PRO User Manual page 35

4. Click the REMOVE PRINTOUT button if you want to pull out
the printout.
• If you removed it earlier you can skip this step by pressing
the ALREADY DONE button
5. Check that the way of the Recoater is not obstructed. If not, confirm with the "DONE" button. The Recoater will be
homing.
Removing printout
Make sure that the path of the Recoater
is not obstructed
BACK
PREPARATION STEP 1/8
Check the Recoater's path.
6. Prepare the IO Box. You will need it to take out the printout easily and cleanly.
Feed Bed
Correct position of the elements of the IO Box to pull out
7. Place the IO Box into the Print Chamber as shown above. We recommend first to insert the folded IO Box into the
Print Chamber and then spread them out to the width of the Print Chamber. Be careful of the elements inside the
Print Chamber and on the Lid.
8. Press the NEXT button.
9. After pressing the NEXT button, the Print Bed is positioned and the printout is ejected.
DONE
Print Bed
printouts.
Removing printout
You can skip the step if you have already
removed the printout
ALREADY DONE
BACK REMOVE PRINTOUT
PREPARATION STEP 1/9
The printout removal screen.
Please wait while
Recoater and Beds get positioned...
Homing...
Print bed Feed bed
• •
PREPARATION STEP 1/9
Recoater's homing screen.
Place and spread IO BOX
in the correct orientation.
Make sure there is a free area
above the print bed inside the tool.
BACK
PREPARATION STEP 2/10
The printer will also help with a suitable screen.
Recoater
•
NEXT
Sinterit LISA PRO User Manual | 35
