SINTERIT LISA PRO User Manual page 26

START
NEW PRINT
CONTROL
PANEL
Main menu screen.
7. The printer will ask you if you have cleaned the powder
after the last printout.
• If yes, press the YES button,
• If not, then NO, THE POWDER IS STILL INSIDE button
- the cleaning process will start. The following steps are
described in the chapter „Finishing the print".
• This message will not appear when you print the first time
after delivery.
8. Prepare the file with the xxx.scode extension in Sinterit
Studio.
9. The prepared xxx.scode file can be sent directly to the
printer (when connected to a Wi-Fi network) or uploaded
via USB Flash Drive.
10. Select the file for printing. You have several options:
• LOAD FROM USB - when the file is saved on the USB Flash
Drive,
• UPLOADS - when the file was sent via Wi-Fi,
• RECENT MODELS - when the file is in the internal memory
of the printer.
11. Select a file from the list and click on it. The file name, printing time and the type of powder to use will appear on
the screen.
12. Prepare a suitable powder and press the NEXT button.
CLEAN
PRINTER
UNLOCKED/
OVERFLOW
START CLEAN
NEW PRINT PRINTER
CONTROL UNLOCKED/
PANEL OVERFLOW
CLICK AND OPEN LID
Unlocking the printer Lid.
Have you cleaned the printer after the last
use?
And it is free from any remainding powder?
NO, POWDER IS STILL INSIDE
BACK
Message about cleaning the printer
after previous printing.
Prepare the file in the Sinterit Studio.
LOAD FROM USB
RECENT MODELS
BACK
Select the file source.
PRESS & LITF UP
YES
UPLOADS
Sinterit LISA PRO User Manual | 26
