SINTERIT LISA PRO User Manual page 30

22. Remove, clean and then re-insert the Laser Protective Glass
. Then press the DONE button.
G
• The complete cleaning process is described in the section
„Maintenance and daily service of the Sinterit Lisa PRO
printer", subsection „Laser Protective Glass - cleaning and
replacing". Chapter 16, subchapter B.
• Remember to use only products with an ethanol-based
solution for cleaning! We recommend using the Alcohol
Pads from the Service Kit.
• Other products (e.g. isopropyl alcohol) can destroy the
Laser Protective Glass.
STOP!
•
Watch out for the elements of the Heating module
•
Do not clean the Laser Protective Glass
•
The cleaning process should be carried out outside of the machine.
23. Gently clean the Pyrometer Window Module
recommend using the Alcohol Pads from the Service Kit.
Wipe to dry and press the DONE button.
24. Clean the Recoater Guide Bar
Alcohol Pads or a cotton cloth soaked in ethyl alcohol.
Press the DONE button.
25. After wiping the Recoater Guide Bar with alcohol, oil it with
silicone oil (available in the Service Kit). A few drops are
enough. Then press the DONE button.
. We
32
. We recommend using
26
BACK
PREPARATION STEP 5/9
Remove, clean and then re-insert the Laser
Protective Glass.
of the device.
24
under running water.
G
Carefully clean the vision
window of the camera
and pyrometer
BACK
PREPARATION STEP 6/9
Clean the Pyrometer Window Module.
BACK
PREPARATION STEP 7/9
Clean the Recoater Guide Bar.
Lubricate guide bar of the
Recoater with silicone grease
BACK
PREPARATION STEP 8/9
Lubricate the Recoater Guide Bar
with silicone oil.
Remove and clean the
laser protective glass.
DONE
DONE
Clean the recoater
guide bar
DONE
DONE
Sinterit LISA PRO User Manual | 30
