Enable Carriers

The IPBS/IPBL has 5 carriers for the North American frequency band and 10 carriers for the
other frequency bands. Under all normal circumstances all carriers should be enabled.
To enable or disable carriers:
1 Select DECT > System.
2 Mark/unmark the Enabled Carriers check boxes.
3 Click "OK".
7.5.8

Enbloc Dialling

With this option enabled the keystrokes on the handsets are buffered in the IPBS/IPBL for a
short period of time before sent to the IP-PBX (use this when the IP-PBX does not support
overlap sending). If disabled the keystrokes are immediately sent to the IP-PBX.
1 Select DECT > System.
2 To enable, mark the Enbloc Dialling check box.
3 Click "OK".
7.5.9

Local R-Key Handling

With this option enabled keypad information is handled locally. If this option is disabled
keypad information is sent transparently to the IP-PBX.
1 Select DECT > System.
2 To enable, mark the Local R-Key Handling check box.
3 Click "OK".

7.5.10 DTMF through RTP Channel

If enabled, DTMF digits are sent as RTP payload directly to the other endpoint. If disabled,
the DTMF is sent in the signalling channel.
1 Select DECT > System.
2 To enable, mark the DTMF through RTP channel.
3 Click "OK".
7.5.11 No Transfer on Hangup
If enabled it will not be possible to do a transfer by hanging up the phone. R+4 must be
pressed.
1 Select DECT > System.
2 To enable, mark the No Transfer on Hangup checkbox.
3 Click "OK".
7.5.12 Configure Coder
Select the preferred coder, and enter the desired frame length. If exclusive is selected for
the coder the IPBS/IPBL is forced to use that coder. With Silence Compression enabled no
information is sent during pauses in the conversation, this is used to save bandwidth.
