Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway
2.2

IP-DECT Gateway

The following versions of the IPBL are available:
• IPBL IP-DECT Gateway VAC/VDC (for 110/230 VAC or 48 VDC)
• IPBL IP-DECT Gateway VDC (for 48 VDC)
2.2.1 Overview
Figure 2.
Figure 2. Overview of the IPBL
Pos. Name
1 Reset
2 Status LED
3 Lan
4 Synchronization
5 Reference
6 Base station 01-16
2.2.2

Power Supply

The power supply are located at the rear of the IPBL. The IPBL can be powered using the
following alternatives:
• 110/230 VAC (only IPBL IP-DECT Gateway VAC/VDC)
• 48 VDC
Note: For more information, see
Software
The software in the IPBL can be updated by downloading new software without
disconnecting the equipment. The new software is stored in flash memory. See
Update on page 56 for information.
2.2.3

LED indication

Figure 3.
Status LED
Not lit
Steady Green
Steady Red
Steady Amber
Figure 4.
2007-06-18/ Ver. E
lan synchronization reference
1 2 ring in ring out in
1 2 3 4 5
Function
Resets the IPBL, see
page 60 for more information.
Indicates the status on the IPBL.
10BASE-T/100BASE-TX Ethernet interface.
Sync ring in and sync ring out interfaces.
Reference sync in and reference sync out interfaces.
ISDN U
5.3 Power the IPBL
Description
Not powered, status is not defined.
Status OK, system is fully operational.
Status Fail, system error condition.
System is in TFTP server mode.
base station 01 02 03 04
09 10 11 12
out
7.13 Reset Using the Reset Button
DECT base station interfaces.
PN
on page 23.
TD 92372GB
05 06 07 08
13 14 15 16
6
7.10
on
5
