Operation; Individual Registration; Assign Handsets To Users - ASCOM IP-DECT Base Station Installation And Operation Manual

Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway

Assign Handsets to Users

1 Select DECT > System.
2 Enable anonymous registration by selecting "With System AC" in the Subscriptions
drop-down list.
3 Click "OK".
4 Perform an "over air subscription" using the system Authentication Code. For
information on how this is done, see the reference guide of the handset.
The handsets' IPEI number appears in the Anonymous list. To view the list: Select
Users > Anonymous.
5 Assign the handset to any user defined in the system by calling the desired
extension and hang up.
6 Go off hook to hear the dial tone and hang up.
7 Repeat step 4 to 6 for all handsets.
8 Under the Configuration menu, select DECT > System.
9 Disable anonymous registration by selecting "Disable" in the Subscription drop-
down list.
10 Click "OK".
6.6.2

Individual Registration

1 Select Users.
2 Click "New".
3 Enter the following information in the corresponding text fields:
• Long Name - The name of the user, need to be unique throughout the system.
This is the name presented in a called party´s display, unless this is configured in
the IP-PBX.
• Name - The user name.
• Number - The phone number extension, need to be unique throughout the
system.
• Password - Optional, is used for registration towards the gatekeeper.
• Display Text - Will be showed in the handset display when the phone is idle.
• IPEI - The unique identification number of the handset.
• Auth. Code - The individual authentication code for this user.
4 Perform an "over air subscription" using the individual authentication code. For
information on how this is done, see the reference guide of the handset.
5 Click "OK".
7

Operation

This section describes the settings in the Configuration and Administration menu, each
subsection represents a sub menu to the Configuration and Administration menu.
Some changes require a reset in order to take effect. It is possible to do several changes
before resetting the IPBS/IPBL.
The GUI for the IPBS and IPBL are similar. Screen shots from the IPBS are used as default.
2007-06-18/ Ver. E
TD 92372GB
31
