Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway

Software

The software in the IPBS can be updated by downloading new software without
disconnecting the equipment. The new software is stored in flash memory. See
Update on page 56 for information.

Connectors

• Two 8-pin RJ45 modular jacks for LAN/PoE and powering
• A 6-pin RJ12 modular jack for factory testing

LEDs

Status of LED1 (lower LED)
Steady Green
Quick flashing amber
Steady Amber
Alternating red/green
Status of LED2 (upper LED)
Not lit
Steady green
Slow flashing green
Flashing amber
Slow flashing amber
Steady amber
Flashing red
Quick flashing red
2007-06-18/ Ver. E
Description
Operational
Download of firmware in progress.
TFTP mode
No Ethernet connection
Description
IPBS operational and no traffic
Air synchronization OK
IPBS operational and traffic
Air synchronization OK
Air synchronization OK and fully occupied with
traffic
Air synchronization inadequate and no traffic
Air synchronization inadequate and fully
occupied with traffic
Air synchronization inadequate and traffic
No air synchronization - searching for air sync
candidates
Download of RFP software in progress
