User Manual
9d24 Mkll Cordless Telephone
2.7.3

Headset

A headset is recommended if you frequently use the phone and/or want to have both
hands free. The handset has a special headset connector that is waterproof. The headset
comes in three versions; with microphone integrated in the cable, with microphone on a
boom and with hearing protection (Peltor). An adapter, that makes it possible to connect
other standard types of Peltor headsets, is also available.
In order to achieve optimal audio quality with the different headset types it is
recommended that the SIM parameter called "Headset type" is altered to match the
headset type being used. The default setting for this parameter is microphone on a boom
i.e. the audio is optimized for using a headset with microphone on a boom.
Note: The handset must be equipped with the factory mounted headset connector.
EX classified Headset
The EX Headset with hearing protection from Peltor must be connected to an EX Headset
Adapter for Peltor Headset.
IMPORTANT: Headset used in combination with an EX classified 9d24 MkII EX-version
2.7.4

Security String

The security string is 800 mm long. Fasten one end to the hinge-type belt clip and the
other end to, for example, your pocket.
3

Basic Operation

3.1

Call List

The twenty last received/dialled telephone numbers are stored in a call list. Open the call
list by pressing the Navigation key
the clock and date function is set, you can on the same day the call was received/dialled,
see the time for the call. The time stamp is changed to a date stamp the following day.
3.2

Make a Call

Note: The headset answering button is only active during a call or when the telephone is
ringing and can thus not be used to get the line when making a call.
Pre-dial
Enter the number and press the Call key
display while dialling. If needed, you can press the Soft key "C" to erase and edit the
number. By using Navigation key
middle of a number.
2007-02-07/ Ver. D
must have the same EX classification as the handset to fulfil the EX
directive.
EX classified headsets must be ordered directly from Peltor®, see the Peltor
homepage (www.peltor.se) for more information.
, or from the menu, see
or
8.2 Contacts
to get the line. The number is shown on the
it is possible to step and add/delete a digit in the
TD 92333GB
on page 32. If
11
