Deutschmann Automation GmbH & Co. KG
12.2 LEDs
The Gateway UNIGATE
LED (EtherNet/IP) Power
LED Link/Act. P1
LED Link/Act. P2
LED Net State
LED Mod State
LED Power
LED State
LEDs 1 / 2 / 4 / 8 (Error No. / Select ID) green
12.2.1 LED "(EtherNet/IP) Power"
This LED is connected directly to the EtherNet/IP supply voltage of the Ethernet/IP-side.
12.2.2 LED "Link/Act. P1"
This LED is directly controlled by the EtherNet/IP-controller, and is illuminated when the gateway
at Port 1 (X3 P1) is in an operable network (link-pulses are received) and it flickers when network
data traffic takes place.
12.2.3 LED "Link/Act. P2"
This LED is directly controlled by the EtherNet/IP-controller, and is illuminated when the gateway
at Port 2 (X3 P2) is in an operable network (link-pulses are received) and it flickers when network
data traffic takes place.
12.2.4 LED "Net State"
Flashes green/red
Lights green
Flashes green
Flashes green/red
Lights red
12.2.5 LED "Mod State"
Flashes green/red
Lights green
Flashes green
Flashes green/red
Lights red
12.2.6 LED "Power"
This LED is connected directly to the (optionally also electrically isolated) supply voltage of the
serial interface (RS232/422/485).
12.2.7 LED "State"
Lights green
Flashes green
Flashes green/red
Lights red
Flashes red
29.9.20
Fieldbus-Gateway UNIGATE
®
CL - EtherNet/IP features 11 LEDs with the following significance:
green
green
green
red/green
red/green
green
red/green
Self-test
Connection available, data exchange active
Waiting for connection establishment
Timeout during connection
IP-address assigned twice
Self-test
Data exchange active
Standby / module is waiting for connection establishment
Module-error
Substantial module-error
Controllable via Script
Controllable via Script
Controllable via Script
General Gateway error (see LEDs Error No.), controllable via Script
UNIGATE is in the configuration / test mode, controllable via Script
®
CX EtherNet/IP - C4Map V. 1.0
Hardware ports, switches and LEDs PROFINET
Supply voltage EtherNet/IP
Ethernet-link pulse found / network data traffic Port 1
Ethernet-link pulse found / network data traffic Port 2
Interface state EtherNet/IP / network status
Module-state
Supply voltage serial interface
User-defined / general Gateway error
User-defined / general Gateway error
35
