Hardware ports, switches and LEDs PROFINET
Connector supply voltage and DEBUG-interface
12.1.1.2
Pin assignment X1 (4-pole screw-plug connector, on the bottom side, at the back)
Pin No.
Name
1
UB (Out)
2
0 V (Out)
3
Rx-Debug
4
Tx-Debug
Attention:
The ground for the DEBUG interface is 0V (Pwr).
12.1.1.3 EtherNet/IP-connector
The plugs (labeled: RJ45 EtherNet/IP) for the connection to EtherNet/IP are available on the bot-
tom side of the device.
Pin assignment X3 P1 (RJ45 up front, i. e. which is located closer to the front panel)
Pin No.
Name
1
TD+
2
TD-
3
RD+
4
5
6
RD-
7
8
Pin assignment X3 P2 (RJ45 at the back, i. e. which is located closer to the DIN-rail)
Pin No.
Name
1
TD+
2
TD-
3
RD+
4
5
6
RD-
7
8
12.1.1.4 Power supply
The device must be powered with 10-33 VDC, The voltage supply is made through the 4-pole
screw-plug connector at the device's bottom side.
Please note that the devices of the series UNIGATE
34
Function
10..33 V supply voltage / DC
0 V supply voltage / DC
Receive signal Debug
Transmit signal Debug
Fieldbus-Gateway UNIGATE
Deutschmann Automation GmbH & Co. KG
Function
Transmission line +
Transmission line -
Receive line +
Receive line -
Function
Transmission line +
Transmission line -
Receive line +
Receive line -
®
should not be operated with AC voltage.
®
CX EtherNet/IP - C4Map . 1.0
29.9.20
