Commissioning guide
19.6 Setting the CANopen
®
Set the CANopen -Node-ID and the baud rate at the fieldbus end of the module on the DIP-
switch (see also chapter 32.4.3).
Attention:
The CANopen
All users in the CANopen
These values are read in only on power-up of the gateway!
®
19.6.1 CANopen
Connect the device to the CANopen

19.6.2 Connection to the process device

Please also read the manual for the process device when commissioning the process device.

19.6.3 Connecting the supply voltage

Please connect 10..33 DC voltage to the terminals provided for this.

19.6.4 Shield connection

Earth the top-hat rail onto which the module has been snapped.

19.7 EtherNet/IP connection

Connect the device to the EtherNet/IP network at the interface labeled "RJ45 EtherNet/IP".
19.8 Connection to the process device
Please also read the manual for the process device when commissioning the process device.

19.9 Shield connection

Earth the top-hat rail onto which the module has been snapped.

19.10 Connecting the supply voltage

Please connect 10..33 DC voltage to the terminals provided for this.

19.11 Project planning

Use any project planning tool for project planning.
If the required EDS file was not supplied with your project planning tool, a sample file can be
found on the Internet (www.deutschmann.com).
