Features - STMicroelectronics B-L462E-CELL1 User Manual

1

Features

• LBAD0ZZ1SE module from Murata powered by STM32L462RE with built-in eSIM (ST4SIM-200M), LTE
Cat M/NBIoT modem (LBAD0XX1SC-DM), and 1 Mbyte of Quad-SPI Flash memory
• Ultra-low-power STM32L4 Series
with 512 Kbytes of Flash memory and 160 Kbytes of RAM in a WLCSP64 package
• 64 Mbytes of onboard Quad-SPI Flash memory from Micron
memory inside the module
• 16 Kbytes of I
• 0.96-inch 128 x 64 OLED screen with SPI interface
• Low-power Audio CODEC with PCM bus and I
• Ultra-low-power 3D accelerometer and 3D magnetometer (LSM303AGR) from STMicroelectronics
• Capacitive digital sensor for relative humidity and temperature (HTS221) from STMicroelectronics
• 260-1260 hPa absolute digital output barometer (LPS22HH) from STMicroelectronics
• 3 user LEDs
• 2 push-buttons (user and reset)
• Board connectors:
– SMA antenna connector
– Two 50-pin 2.54 mm pitch headers
– STMod+
– micro-SIM card slot
– 3.5 mm CTIA stereo headset jack including analog microphone input
– USB Micro-B connectors for power, USARTs, USB device, and ST-LINK/V2-1
– TAG10
– mikroBUS
– ESP‑01 expansion connector
– Grove Seeed Studio
• Flexible power-supply options: ST-LINK USB, User USB, UART USB, Power USB, or three AAA batteries
• On-board ST-LINK/V2-1 debugger/programmer with USB re-enumeration capability: mass storage, Virtual
COM port, and debug port
• End-to-end connectivity applications
• Low‑power
• Support of a wide choice of Integrated Development Environments (IDEs) including IAR Embedded
Workbench
Note: Arm is a registered trademark of Arm Limited (or its subsidiaries) in the US and/or elsewhere.
UM2743 - Rev 1
STM32L462REY6TR
2
C EEPROM (M24128-DFMN6TP) from STMicroelectronics
™
expansion connectors
™
breadboard, I
cellular network services from Truphone
®
, MDK-ARM, and STM32CubeIDE
microcontroller based on the Arm
®
, exclusive with the 1 MByte of Quad-SPI Flash
2
C interface (MAX9867ETJ+ from Maxim)
2
C, and UART expansion connectors
®
UM2743
Features
® ®
Cortex -M4 core
page 2/58
