ST-LINK debug connector

The ST-LINK debug connector is a 6-pin, 2.54 mm pitch male connector. It provides access to the embedded
SWJ-DP interface of the STM32F103CBT6 MCU. This SWJ-DP interface is a combined JTAG and serial wire
debug port that enables either a serial wire debug or a JTAG probe, to be connected to the target.
Connector
CN5
8.6

INT pins of sensors

Connector
CN7
UM2743 - Rev 1
Table 9. ST-LINK debug connector pinout
Pin number Pin name
1 GND
2 T_JTCK
3 GND
4 T_JTMS
5 T_NRST
6 T_SWO
Table 10.
Pin number
1
2
Signal name STM32L4 pin
GND
TCK/SWCLK
GND
TMS/SWDIO
T_NRST
T_SWO
INT pins of sensors
Pin name Signal name
DRDY INT_HUM
INT/DRDY INT_PRE
UM2743
ST-LINK debug connector
Function
- Power
PA14 Serial wire clock
- Power
PA13 Serial wire data I/O
NRST RESET
PB3 Serial wire output
Function
HTS221 INT
LPS22HH INT
