Figure 3.
B-L462E-CELL1 Discovery kit for IoT nodes (top view)
USB PWR (CN11)
USB ST-LINK (CN9)
SIM card slot (CN2)
Modem LED status
(PSM and TX)
Current measurement
jumper (JP1)
ST-LINK MCU (U12)
LBAD0ZZ1SE (U5)
1.8V LDO (U19)
User LED(LD1,LD2,LD3)
ST-LINK COM (LD6)
STMod+(P1)
Flash (U8)
OLED screen (U1)
LSM303AGR (U7)
TAG10 (CN3)
HTS221 (U10)
LPS22HH (U6)
Sensor interrupt
pins (CN7)
Reset button (B1)
USB UART (CN10)
User button (B2)
SMA connector (CN1)
User USB (CN8)
