7.6 Changing the travel drive oil

L WARNING
21.12.2017
To add oil, completely remove the lubricating point plug and
6.
pour fresh oil into the threaded hole until it overflows.
Tighten the closure of the lubricating point (1).
7.
Risk of injury due to oil coming into contact with skin.
Contact with oil can cause severe skin disorders and other
severe injuries.
– Wear gloves and safety glasses with side protection.
– Avoid skin contact with used oil.
– If skin contact occurs, thoroughly wash off the affected
area.
– Do not inhale oil vapors or swallow oil.
Information Mixing different types of oils, lubricants and oper-
ating fluids is prohibited. Only mix the same type of or identical
(same specification) oils, lubricants and operating fluids from the
same manufacturer.
Park the machine on an even and hard surface so the lubri-
1.
cating points (1) and (2) are positioned as in .
Switch off the diesel engine
2.
Place a collecting vessel under the closure for lubricating
3.
point (1) and lubricating point (2).
Loosen the closure for lubricating point (1) so the oil can flow
4.
out better.
Loosen and remove the closure for lubricating point (2).
5.
Let the used oil drain completely.
6.
Tighten the closure of the lubricating point (2).
7.
Preliminary
GHC75 Telescopic crane
undercarriage
Changing the travel drive oil
69
