Machine
Check and lubricate the manual lubrication stations
Lubrication plan, upper carriage,
lubricating bar
Position
1
2
3
4
5
6
7
8
9
10
11
12
24
The lubricating bar is at the front, to the right, under the service
hatch.
lubrication point
Derricking cylinder, lower
Output side winch bearing point
Boom mounting
Boom mounting
Slewing ring, inner
Slewing ring, inner
Slewing ring, inner
Slewing ring, inner
Slewing ring, inner
Slewing ring, inner
Slewing ring, inner
Slewing ring, inner
Preliminary
GHC75 Telescopic crane
Lubricating nipple on the
lubricating bar
M8
M6
M10
