Crane Care
Dewatering the diesel prefilter
Changing the filter cartridge
21.12.2017
L WARNING! Risk of injury from rotating or hot engine parts!
Persons can be injured by moving or hot engine parts.
– Only perform maintenance when the drive engine is shut
down and the cooling system has cooled down.
1. Open the service door (1).
Place a suitable collecting vessel under the drain valve (4).
2.
Open the drain valve (4).
3.
Drain water and contamination from the water container until
4.
fuel flows out.
Close the drain valve (4).
5.
Close the service door (1).
6.
Information
–
After dismantling the filter, clean all parts, check for damage or
wear and replace parts if necessary.
–
Ensure the utmost cleanliness when replacing the filter ele-
ment! In addition, pay attention to the description imprinted on
the filter cartridge!
Open the service door (1).
1.
2. Place a suitable collecting vessel under the drain valve (4).
Open the drain valve (4).
3.
Drain water and contamination from the water container until
4.
fuel flows out.
5. Close the drain valve (4).
Unscrew the screw cap (5) from the housing (2) and pull out
6.
the filter element that is fastened to it.
Preliminary
GHC75 Telescopic crane
Diesel engine service
Diesel pre-filter
