53-1004408-11 Installation Guide
Table 7: System Power LED Patterns during Normal Operation
LED Color
No light
Steady green

System Status LED

See the following table to interpret the system status LED.
Table 8: System Status LED Patterns during Normal Operation
LED Color
No light
Steady green
Steady amber (for more than five seconds
—can take over a minute to complete
POST)
Steady amber (for more than a few
minutes)
Flashing amber/green

Management Port LEDs

See the following table to interpret the management port LEDs.
Table 9: Management Port LED Patterns during Normal Operation
LED Function/State
Link/SpeedGreen LED; ON
Link/Speed Amber LED; ON
ActivityGreen LED: BLINK
Broadcom
Status of Hardware
System is off or there is an internal power
supply failure.
System is on and power supplies are
functioning properly.
Status of Hardware
System is off or there is no power.
POST and initialization is completed.
System is on and functioning properly.
System is going through the power-up
process.
Unknown state, boot failed, or the system is
faulty.
When POST completes and the switch has
failed, steady amber may result.
Attention is required. A number of variables
can cause this status, including power
supply failure, a fan failure, or one or
more environmental ranges have been
exceeded.
1000Mb/s Link
10/100Mb/s Link
Presence of activity
®
Brocade G610 Switch Hardware Installation Guide
Recommended Action
Verify that system is powered on, the power
cables attached, and your power source is
live.
If the system power LED is not green, the
unit may be faulty.
Contact your solution provider.
No action required.
Recommended Action
Verify that system is on and has completed
booting.
No action required.
No action required.
Perform the following steps:
1. Connect a serial cable to the system.
2. Reboot the system.
3. Check the failure indicated on the
system console
4. Contact your solution provider.
Check the management interface and the
error log for details on the cause of the
status.
Contact your solution provider.
Status of the Hardware
53-1004408-11
