Broadcom G610 Hardware Installation Manual page 59

53-1004408-11 Installation Guide
Data Port Specifications (Fibre Channel)
Port Numbers
0 to 23 16G or 32G SFP+ optical ports
Fibre Channel Data Transmission Ranges
Port Speed (G)
4 50
62.5
9
8 50
62.5
9
16 50
62.5
9
32 50
62.5
9
Serial Port Specifications (Pinout RJ-45)
NOTE
These specifications are for connectors on Brocade platforms only.
Pin
1
2
3
4
5
6
Broadcom
Media Type
Cable Size
Short Wavelength (SWL)
(Microns)
150m (492 ft) (OM2)
380m (1264 ft) (OM3)
400m (1312 ft) (OM4)
70m (229 ft)
N/A
50m (164 ft) (OM2)
150m (492 ft) (OM3)
190m (623 ft) (OM4)
21m (68 ft)
N/A
35m (115 ft) (OM2)
100m (328 ft) (OM3)
125m (410 ft) (OM4)
15m (49 ft)
N/A
70m (230 ft) (OM3)
100m (328 ft) (OM4)
N/A
N/A
Not supported
Not supported
UART1_TXD
GND
GND
UART1_RXD
Switch mode (default): 8-, 16-, and 24-port configurations (8-port
increments through Ports on Demand [PoD] licenses); can be an F_Port,
an N_Port, or an E_Port.
Brocade Access Gateway default port mapping: 16 F_Ports, 8 N_Ports.
Long Wavelength (LWL)
N/A
N/A
30 km (18.6 miles)
N/A
N/A
10 km (6.2 miles)
25 km (15.5 miles)
N/A
N/A
10 km (6.2 miles)
25 km (15.5 miles)
N/A
N/A
10 km (6.2 miles)
Signal
®
Brocade G610 Switch Hardware Installation Guide
Description
Extended Long
Wavelength (ELWL)
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Description
N/A
N/A
Transmit data
Logic ground
Logic ground
Receive data
53-1004408-11
59
