CAUTION
Do not use the port cover tabs to lift the module. They are not designed to support the weight of the module,
which can fall and be damaged.

Laser Precautions

DANGER
All fiber-optic interfaces use Class 1 lasers.
DANGER
Use only optical transceivers that are qualified by Broadcom and comply with the FDA Class 1 radiation
performance requirements defined in 21 CFR Subchapter I, and with IEC 60825 and EN60825. Optical products
that do not comply with these standards might emit light that is hazardous to the eyes.

Facility Requirements

Before installing the device, be sure that the following facilities requirements are met.
Table 3: Facility Requirements
Type
•
Electrical
•
See
•
Thermal
•
•
Rack (when rack-
mounted) •
•
•

Quick Installation Checklist

These checklists provide a high-level overview of the basic installation process from the planning stage to the point where
the device comes online and is ready to be deployed. Completing all the tasks in the suggested order ensures successful
installation. Print these checklists and take them to the installation site.
Preinstallation Tasks
Review all installation requirements ahead of time as part of your site preparation. Careful planning and site preparation
ensure seamless installation, especially when installing multiple devices.
Broadcom
Adequate supply circuit, line fusing, and wire size, as specified by the electrical rating on the switch
nameplate
Circuit protected by a circuit breaker and grounded in accordance with local electrical codes
Brocade G610 Switch Technical Specifications
A minimum airflow of 54.5 m3/hour (32.1 cubic ft/min.) available in the immediate vicinity of the switch
Although this airflow may exceed the airflow maximum listed in the device technical specifications, the
additional airflow is recommended to pressurize the inlet (cool isle) side of rack installations relative to the
exhaust side to minimize recirculation of hot air back to the inlet side.
Ambient air temperature not exceeding 40°C (104°F) while the switch is operating
One rack unit (1U) in a 48.3 cm (19-in.) rack
All equipment in the rack grounded through a reliable branch circuit connection
The additional weight of the switch not to exceed the rack's weight limits
Rack secured to ensure stability in case of unexpected movement
Brocade
Requirements
for complete power supply specifications.
®
