FC Port Status LEDs

See the following table to interpret the FC port status LEDs.
Table 10: FC SFP+ Port Status LED Patterns during Normal Operation
LED Color
No light
Steady green
Slow-flashing green (on 1 second; then off
1 second)
Fast-flashing green (on 1/4 second; then off
1/4 second)
Flickering green
Steady amber
Slow-flashing amber (on 2 seconds; then
off 2 seconds)
Fast-flashing amber (on 1/2 second; then
off 1/2 second)

Interpreting POST Results

Each time the switch is powered on, rebooted, or reset, it performs a power-on self-test (POST). The total boot time with
the POST can be several minutes. The POST can be omitted after subsequent reboots by using the fastboot command
or entering the diagDisablePost command to persistently disable the POST. The success or failure results of the
diagnostic tests that run during the POST can be monitored through LED activity, the error log, or the command line
interface. During the POST, the LEDs flash different colors.
The POST performs the following tasks:
•
Conducts preliminary POST diagnostics.
•
Initializes the operating system.
•
Initializes the hardware.
•
Runs diagnostic tests on several functions, including the circuitry, port functionality, memory, statistics counters, and
serialization.
Broadcom
Status of Hardware
Indicates one of the following:
•
No signal or light carrier (media or
cable) detected.
•
The device may be currently initializing.
•
The connected device is configured in
an offline state.
Port is online (connected to an external
device) but has no traffic.
Port is online but segmented because of
a loopback cable or incompatible device
connection.
Port is online and an internal loopback
diagnostic test is running.
The Port is online and frames are flowing
through the port.
Port is receiving light or signal carrier, but it
is not online yet.
Port is disabled because of diagnostics or
portDisable
the command.
SFP+ or port is faulty.
®
Brocade G610 Switch Hardware Installation Guide
Recommended Action
•
Verify the power LED is on, and check
the SFP+ and cable.
•
Verify the device is not currently being
initialized.
•
Verify the status of the connected
device.
No action required.
Verify that the correct device is attached to
the switch.
No action required.
No action required.
No action required.
Reset the port.
portCfgPersistentDisable
The
command is persistent across reboots.
Reset the port.
Replace the SFP+. Must be a Brocade-
branded SFP+.
