Instruments

Setting the Gear Change Lights

Note:
• The gear change lights will not
operate below 3,500 rpm to avoid
the lights operating at idle.
To change the gear change light modes,
with the motorcycle stationary and in
neutral turn the ignition to the ON
position.
Press and release the SCROLL button
until SEtUP is shown in the display
screen then press the SET button.
Press and release the SCROLL button
until SHIFt is shown then press the SET
button. The current mode will be
displayed and the corresponding gear
change lights will illuminate.
Press and release the SCROLL button
until the desired gear change light mode
is shown then press the SET button.
The display will scroll through in the
following order:
• 6 (6 LED mode);
• 3 (3 LED mode);
• SE (Sequential mode);
• OFF (Gear change lights off).
68
Note:
• The motorcycle is delivered from
the factory with the gear change
light set to the 6 LED mode at
3,500 rpm.
3
1
4
1. Gear change lights
2. Display screen (6 mode shown)
3. SCROLL Button
4. SET Button
When the gear change light mode has
been selected, the tachometer needle
will move round to the current set
position. The rpm will be shown in the
display screen with the current set
units flashing.
2
3 1
1. Current set units
2. SCROLL button
3. SET button
2
