Passenger Seat and Seat Cowl

Note:
• This section applies to both the
passenger seat and the seat cowl.
The seat cowl is fitted to certain
models only, or is available as an
accessory.
2
1
cjxc
1. Seat lock
2. Passenger seat
The passenger seat lock is located on
the left hand side of the rear bodywork,
in line with the footrest mounting rail.
To remove the passenger seat, insert
the ignition key into the seat lock and
turn it anticlockwise while pressing
down on the front of the seat. This will
release the passenger seat from its lock
and allow it to be slid forwards for
complete removal from the motorcycle.
General Information
Warning
Never ride the motorcycle with the
passenger seat detached or removed.
To prevent detachment of the seat
during riding, after fitting always grasp
the seat and pull firmly upwards. If the
seat is not correctly secured, it will
detach from the lock. A loose or
detached seat could cause loss of
motorcycle control and an accident.
To refit the passenger seat, engage the
seat's tongue under the bracket, align
the locating peg to the lock and press
down engaging the seat lock. An audible
click can be heard when the seat is fully
engaged in its lock.
1. Locating peg
2. Lock
3. Bracket
4. Tongue
97
