KEY FEATURES
•
STM32L496VGT6 microcontroller featuring Arm
DMIPS and three 12-bit ADC at 5 Msps
•
Programmable voltage source from 1.8 V to 3.3 V
•
Static current measurement from 1 nA to 200 mA
•
Dynamic measurements:
–
–
–
–
–
•
Mode standalone:
–
–
–
•
Mode controlled:
–
–
–
•
Four status LEDs
•
Target board connectors:
–
–
•
Flexible input power-supply options:
–
–
–
100 kHz bandwidth, 3.2 Msps sampling rate
Current from 100 nA to 50 mA
Power measurement from 180 nW to 165 mW
Energy measurement computation by power measurement time integration
Execution of EEMBC ULPMark™ tests
Monochrome LCD, 2 lines of 16 characters with backlight
4-direction joystick with selection button
Enter and Reset push-buttons
Connection to a PC through USB FS Micro-B receptacle
Command line (Virtual COM port) or
STM32CubeMonitor-Power PC tool.
®
ARDUINO Uno and Nano connectors
Basic connector (white): 4 wires
USB Micro-B (VBUS)
External power connector (7 V to 10 V)
ARDUINO Uno and Nano connectors (pin 5 V)
®
AN4989 Rev 3
STM32 ecosystem outlines
®
Cortex -M4 core at 80 MHz / 100
