UNIT INSTALLATION

The instructions and guidelines provided in this section cover hardware installation topics such as wall
mounting/rack mounting the unit and installing option cards. These instructions are presented as follows:
• Mounting Options on page 42
• Supplying Power to the Unit on page 44
• Installing Dial Backup and Network Interface Modules on page 45
• Installing the NetVanta VPN Accelerator Card (P/N 1202368L1) on page 47
For information on router configuration for a specific application, refer to the quick start documents
provided on your ADTRAN OS System Documentation CD. For details on the command line interface,
refer to the AOS Command Reference Guide (also included on your CD).
To prevent electrical shock, do not install equipment in a wet location or during an
electrical storm.
Electronic modules can be damaged by static electrical discharge. Before handling
modules, wear an antistatic discharge wrist strap to prevent damage to electrical
components. Place modules in antistatic packing material when transporting or storing.
When working on modules, always place them on an approved antistatic mat that is
electrically grounded.

Tools Required

The following customer-provided tools are required for the hardware installation of the NetVanta 4305:
• Ethernet cable
• Network cable (module dependent)
• DSX-1 cable (T1/FT1 + DSX-1 module only)
• G.703 cable (E1/FE1 + G.703 module only)
• DBU cable (dial backup functions require an optional DIM)
• Phillips-head screwdriver (rack mounted applications only)
To access the command line interface (CLI) of the NetVanta 4305, you will also need a
VT100 terminal or PC with terminal emulation software and a console port cable.
Instructions on how to access the CLI are given in the AOS Command Reference Guide
(provided on the ADTRAN OS System Documentation CD).
