August 2019
NetVanta 4300/4400 Series
Hardware Installation Guide
NetVanta 4305 Chassis (AC)
NetVanta 4305 Chassis (DC)
NetVanta 4430 Chassis
Enhanced Feature Pack (Hardware and Software) for IPsec VPN Upgrade (NetVanta 4305)
Enhanced Feature Pack Software for IPsec VPN Upgrade (NetVanta 4430)
NetVanta 56K/64K Network Interface Module
NetVanta T1/FT1 NEBS Network Interface Module
NetVanta T1/FT1 Network Interface Module
NetVanta T1/FT1 + DSX-1 Network Interface Module
NetVanta Dual T1 Network Interface Module
NetVanta Octal T1/E1 Wide Module
NetVanta E1/FE1 Network Interface Module
NetVanta E1/FE1 + G.703 Drop Network Interface Module
NetVanta Serial Network Interface Module
NetVanta SHDSL Network Interface Module, Annex A
NetVanta SHDSL Network Interface Module, Annex B
NetVanta ADSL Network Interface Module, Annex A
NetVanta ADSL Network Interface Module, Annex B
NetVanta USB WWAN Network Interface Module (NetVanta 4430 only)
NetVanta Analog Modem Dial Backup Interface Module
NetVanta ISDN BRI Dial Backup Interface Module
NetVanta ISDN S/T Dial Backup Interface Module
SODIMM, 256/512 MB (NetVanta 4430)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NetVanta 4300 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ADTRAN NetVanta 4300 Series

Summary of Contents for ADTRAN NetVanta 4300 Series

  • Page 1 NetVanta 4300/4400 Series Hardware Installation Guide 1202890E1 NetVanta 4305 Chassis (AC) 1200950G1 NetVanta 4305 Chassis (DC) 1700630E1 NetVanta 4430 Chassis 4200368L1 Enhanced Feature Pack (Hardware and Software) for IPsec VPN Upgrade (NetVanta 4305) 1950730G2 Enhanced Feature Pack Software for IPsec VPN Upgrade (NetVanta 4430) 1200861L1 NetVanta 56K/64K Network Interface Module 1200862L2#NEBS...
  • Page 2 To the Holder of the Manual The contents of this manual are current as of the date of publication. ADTRAN reserves the right to change the contents without prior notice. In no event will ADTRAN be liable for any special, incidental, or consequential damages or for commercial losses even if ADTRAN has been advised thereof as a result of issue of this publication.
  • Page 3 NetVanta 4300/4400 Series Conventions Conventions Notes provide additional useful information. Cautions signify information that could prevent service interruption or damage to equipment. Warnings provide information that could prevent injury or endangerment to human life. 61200890E2-34T Copyright © 2019 ADTRAN, Inc.
  • Page 4 Additional safety guidelines, such as Waste Electrical and Electronic Equipment (WEEE), are given in the document NetVanta Safety and Regulatory Information available at https://supportforums.adtran.com. Save These Important Safety Instructions Copyright © 2019 ADTRAN, Inc. 61200890E2-34T...
  • Page 5 Advance notification and the opportunity to maintain uninterrupted service are given. 4. If experiencing difficulty with this equipment, please contact ADTRAN for repair and warranty information. The telephone company may require this equipment to be disconnected from the network until the problem is corrected, or it is certain the equipment is not malfunctioning.
  • Page 6 1200864L1 Analog Modem DIM FCC Part 15, Class A FCC Part 15 Class A 1200865L1 ISDN BRI DIM EN 55022 Class A EN 55022 Class A 1200875L1 ISDN S/T DIM EN 55024 EN 55024 Copyright © 2019 ADTRAN, Inc. 61200890E2-34T...
  • Page 7 Denial of Service (DoS) attacks, loss or theft of data, and the unauthorized or illegal use of said equipment. ADTRAN OFFERS NO WARRANTIES, EITHER EXPRESSED OR IMPLIED, REGARDING THE PREVENTION, DETECTION, OR DETERRENCE OF TOLL FRAUD, NETWORKING ATTACKS, OR UNAUTHORIZED, ILLEGAL, OR IMPROPER USE OF ADTRAN EQUIPMENT OR SOFTWARE.

  • Page 8: Table Of Contents

    Using a USB Cellular Modem with the NetVanta USB WWAN NIM ......51 61200890E2-34T Copyright © 2019 ADTRAN, Inc.
  • Page 9 Appendix A. Connector Pin Definitions..........56 61200890E2-34T Copyright © 2019 ADTRAN, Inc.
  • Page 10 Figure 27. CompactFlash Card Installation ..........55 61200890E2-34T Copyright © 2019 ADTRAN, Inc.
  • Page 11 ISDN S/T DBU Connector Pinouts ......... . . 61 61200890E2-34T Copyright © 2019 ADTRAN, Inc.

  • Page 12: Introduction

    For information on switch configuration for a specific application, refer to the configuration guides provided on ADTRAN Support Community. For details on the command line interface (CLI), refer to the Guide. All other related documents are also available online at  Command Reference http://supportforums.adtran.com. 61200890E2-34T Copyright © 2019 ADTRAN, Inc.

  • Page 13: Physical Descriptions

    • Integrated IP router with bridging • RIP Versions 1 and 2, OSPF, and BGP routing protocols • IP encapsulation over Frame Relay (RFC 1490) • ADTRAN Operating System (AOS) CLI • SNMP management ® • n-Command network management •...

  • Page 14: Netvanta 4305 Shipping Contents

    After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damaged in transit, immediately file a claim with the carrier and contact ADTRAN Customer Service (refer to the Support page on the ADTRAN website at http://www.adtran.com/support).

  • Page 15: Netvanta 4305 Front Panel Design

    Octal T1/E1 Wide Module. The SLOT 3 WIDE MODULE SLOT 2 NET/DBU option slots support various NIM plug-in modules. These option modules are SLOT 1 NET/DBU described in the section Option Modules on page 61200890E2-34T Copyright © 2019 ADTRAN, Inc.

  • Page 16: Netvanta 4430

    • Integrated RS-232 DCE configuration port (DB-9) • Optional dial backup (ISDN BRI DIM, ISDN S/T DIM, or analog modem DIM) • Dimensions: 17.22-inch W x 1.72-inch H x 10.99-inch D Copyright © 2019 ADTRAN, Inc. 61200890E2-34T...

  • Page 17: Network Interface Modules And Dial Backup Interface Modules Supported

    After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damaged in transit, immediately file a claim with the carrier and contact ADTRAN Customer Service (refer to the Support page on the ADTRAN website at http://www.adtran.com/support).

  • Page 18: Figure 4. Netvanta 4430 Front Panel Layout

    Table A-1 on page 56 for the Ethernet port pinouts. The ETH 0/1 Ethernet port provides the following: • 10Base-T or 100Base-T with a single connector • Auto-negotiation • CSMA/CD • IEEE 802.3 compatibility • Auto MDIX Copyright © 2019 ADTRAN, Inc. 61200890E2-34T...

  • Page 19: Netvanta 4430 Rear Panel Design

    The NetVanta 4430 front panel contains a slot for nonvolatile configuration storage ® CompactFlash and compressed code storage. ADTRAN supports any industry standard 1 GB CompactFlash card. Refer Installing a CompactFlash Card on page NetVanta 4430 Rear Panel Design Figure 5 shows the NetVanta 4430 rear panel.

  • Page 20: Netvanta 4300/4400 Series Front Panel Leds

    Green (flashing) There is data activity on the card (e.g., for the Octal T1 module, this indicates TD/RD data). WIDE SLOT There is no test running. TEST Amber (solid) The card is in test mode. Copyright © 2019 ADTRAN, Inc. 61200890E2-34T...

  • Page 21: Option Modules

    Refer to Using a USB Cellular Modem with the NetVanta USB WWAN NIM on page 51 for details on installing and removing the USB from the USB WWAN NIM. 61200890E2-34T Copyright © 2019 ADTRAN, Inc.

  • Page 22: Option Module Shipping Contents

    Dual T1 Network Interface Module • Quick start guide • Two 15-foot RJ-45 to RJ-45 cable (ADTRAN P/N 3125M008@A) NetVanta Octal T1/E1 Wide NIM (1202843E1) Shipments of the Octal T1/E1 Wide Option Module include the following items: • Octal T1/E1 Wide Network Interface Module •...
  • Page 23 Shipments of the E1/FE1 + G.703 Drop NIM include the following items: • E1/FE1 + G.703 Network Interface Module • Quick start guide • 15-foot RJ-45 to RJ-45 cable (ADTRAN P/N 3125M008@A) NetVanta Serial NIM (1200866E1) Shipments of the Serial NIM include the following items: • Serial Network Interface Module •...
  • Page 24 Analog Modem Dial Backup Interface Module • Quick start guide • 7-foot RJ-45 to RJ-11 cable (ADTRAN P/N 3125M007@A) NetVanta ISDN BRI DIM (1200865L1) Shipments of the ISDN BRI DIM include the following items: • ISDN BRI Dial Backup Interface Module •...

  • Page 25: Network Interface Modules

    Storage Temperature: -20°C to 70°C Clock Source Relative Humidity: Up to 95 percent,  • • Network noncondensing • Internal Physical Diagnostics • Dimensions: 2.75-inch W x 4.25-inch D • CSU and DSU Loopbacks 61200890E2-34T Copyright © 2019 ADTRAN, Inc.

  • Page 26: Netvanta T1/Ft1 Nim (P/N 1202862L1)

    Operating Temperature: 0°C to 50°C • Connector: RJ-48C • Storage Temperature: -20°C to 70°C Relative Humidity: Up to 95 percent,  • Clock Source • Network noncondensing • Internal Physical • Dimensions: 2.75-inch W x 4.25-inch D Copyright © 2019 ADTRAN, Inc. 61200890E2-34T...

  • Page 27: Netvanta T1/Ft1 Nebs Nim (P/N 1200862L2#Nebs)

    Operating Temperature: 0°C to 50°C Clock Source • Storage Temperature: -20°C to 70°C • Network Relative Humidity: Up to 95 percent,  • • Internal noncondensing Physical • Dimensions: 2.75-inch W x 4.25-inch D 61200890E2-34T Copyright © 2019 ADTRAN, Inc.

  • Page 28: Netvanta T1/Ft1 + Dsx-1 Nim (P/N 1202863L1)

    Line Codes: AMI, B8ZS • DSX-1 Interface to PBX Physical • Dimensions: 2.75-inch W x 4.25-inch D • Framing: D4 (SF) or ESF • Line Length: 0 to 655 feet and -7.5 dB • Connector: RJ-48C Copyright © 2019 ADTRAN, Inc. 61200890E2-34T...

  • Page 29: Netvanta Dual T1 Nim (P/N 1200872L1/1202872L1)

    The 1200872L1 Dual T1 module supports the analog modem (1200864L1), ISDN BRI (1200865L1), and ISDN S/T (1200875L1) DIMs for dial backup applications. The 1202872L1 Dual T1 module supports only the analog modem (1200864L1) DIM for dial backup applications. 61200890E2-34T Copyright © 2019 ADTRAN, Inc.

  • Page 30: Netvanta Octal T1/E1 Wide Module (P/N 1202843E1)

    Input Signal: 0 to -30 dB (DS1) on all E1 interfaces (1 through 8) • FE1 Line Rate: Channelized timeslot (in multiples of 64 kbps) • Connector: RJ-48C A different service provider can be used on each interface. Each interface has an independent clock. Copyright © 2019 ADTRAN, Inc. 61200890E2-34T...

  • Page 31: T1/E1 Mode Dip Switch

    The T1/E1 Wide Module is shipped with the T1/E1 mode switch (located on the circuit board) set to T1. If you require E1 functionality, use your thumbnail to slide the E1 mode switch to the position (as shown in the figure below). 61200890E2-34T Copyright © 2019 ADTRAN, Inc.

  • Page 32: Netvanta E1/Fe1 Nim (P/N 1200868E1/L1)

    Dimensions: 2.75-inch W x 4.25-inch D • Internal Diagnostics • Test Pattern Generation and Detection: QRSS, 511, all ones, all zeros • Network loopbacks • Network performance data (15 minutes and 24 hours) • Alarm generation and detection Copyright © 2019 ADTRAN, Inc. 61200890E2-34T...

  • Page 33: Netvanta E1/Fe1 + G.703 Drop Nim (P/N 1200878E1/L1)

    Storage Temperature: -20°C to 70°C • Capacity: 1 to 31 timeslots • Relative Humidity: Up to 95 percent, • Connector: RJ-48C noncondensing Clock Source Physical • Network • Dimensions: 2.75-inch W x 4.25-inch D • Internal • Through 61200890E2-34T Copyright © 2019 ADTRAN, Inc.

  • Page 34: Netvanta Serial Nim (P/N 1200866E1)

    14) can be configured by the user as a V.35, an X.21 (V.11), or an EIA 530 interface. This module supports rates up to a maximum of 10 Mbps. An additional V.35 (ADTRAN P/N 1200873L1), X.21 (ADTRAN P/N 1200874L1), or EIA 530 (P/N 1200883L1) cable is required (see Caution below). See...

  • Page 35: Netvanta Adsl Nim, Annex A (P/N 1202869E1)

    Relative Humidity: Up to 95 percent, • ATM Forum UNI 3.1/4.0 PVC noncondensing • ATM class of service (UBR) • ATM F5 OAM Physical • Dimensions: 2.75-inch W x 4.25-inch D • Up to 16 virtual circuits 61200890E2-34T Copyright © 2019 ADTRAN, Inc.

  • Page 36: Netvanta Adsl Nim, Annex B (P/N 1202889E1)

    Storage Temperature: -20°C to 70°C • ATM class of service (UBR) • Relative Humidity: Up to 95 percent, • ATM F5 OAM noncondensing • Up to 16 virtual circuits Physical • Dimensions: 2.75-inch W x 4.25-inch D Copyright © 2019 ADTRAN, Inc. 61200890E2-34T...

  • Page 37: Netvanta Shdsl Nim, Annex A (P/N 1200936E1)

    • Storage Temperature: -20°C to 70°C • Relative Humidity: Up to 95 percent, Clock Source • CPE Operating Mode: Network noncondensing • CO Operating Mode: Internal Physical • Dimensions: 2.75-inch W x 4.25-inch D 61200890E2-34T Copyright © 2019 ADTRAN, Inc.

  • Page 38: Netvanta Shdsl Nim, Annex B (P/N 1200937E1)

    • Storage Temperature: -20°C to 70°C Clock Source • CPE Operating Mode: Network • Relative Humidity: Up to 95 percent, • CO Operating Mode: Internal noncondensing Physical • Dimensions: 2.75-inch W x 4.25-inch D Copyright © 2019 ADTRAN, Inc. 61200890E2-34T...

  • Page 39: Netvanta Usb Wwan Nim (P/N 1702803F1)

    NetVanta USB WWAN NIM Quick Start Guide or the USB WWAN NIM and the Cellular Interface Configuration Guide available on ADTRAN’s Support Forum (https://supportforums.adtran.com). See Table A-12 on page 60 for the USB WWAN connector pinouts. WWAN Figure 19. NetVanta USB WWAN NIM...

  • Page 40: Dial Backup Interface Modules

    Relative Humidity: Up to 95 percent, noncondensing Physical • Dimensions: 2.5-inch W x 3.75-inch D The Analog Modem DIM can be used in two different modes: 1. Backup interface for a primary connection. 2. CONSOLE port for remote dial-in access. Copyright © 2019 ADTRAN, Inc. 61200890E2-34T...

  • Page 41: Netvanta Isdn Bri Dim (P/N 1200865L1)

    IC CS-03 • UL/CUL 60950-1 Environmental • Operating Temperature: 0°C to 50°C • Storage Temperature: -20°C to 70°C • Relative Humidity: Up to 95 percent, noncondensing Physical • Dimensions: 2.5-inch W x 3.75-inch D 61200890E2-34T Copyright © 2019 ADTRAN, Inc.

  • Page 42: Netvanta Isdn S/T Dim (P/N 1200875L1)

    IEC 60950-1 • AS/NZS 60950-1 Environmental • Operating Temperature: 0°C to 50°C • Storage Temperature: -20°C to 70°C • Relative Humidity: Up to 95 percent, noncondensing Physical • Dimensions: 2.5-inch W x 3.75-inch D Copyright © 2019 ADTRAN, Inc. 61200890E2-34T...

  • Page 43: Unit Installation

    Ethernet cables that run outside the building in which the unit is housed will void the user's warranty and could create a fire or shock hazard. To connect an ADTRAN unit to Ethernet cables that run outside the building, ADTRAN's Ethernet Port Protection Device (EPPD) (P/N 1700502G1) must be connected between the unit and the outside plant cable.

  • Page 44: Tools Required

    • Reliable grounding of rack-mounted equipment should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuit (e.g., use of power strips). Copyright © 2019 ADTRAN, Inc. 61200890E2-34T...

  • Page 45: Rack Mounting Netvanta 4300/4400 Series

    Have an assistant hold the unit in position as you install two #6 to #10 wood screws through the unit’s brackets and into the mounted board. Proceed to the steps given in Supplying Power to the Unit on page 61200890E2-34T Copyright © 2019 ADTRAN, Inc.

  • Page 46: Supplying Power To The Unit

    (1700630G1#120) or 240 VAC, 50/60 Hz (1700630G1#240) power supply. Plugging these units into an incompatible power source will damage the unit. Refer to the label on the unit before connecting the unit to the power source. Copyright © 2019 ADTRAN, Inc. 61200890E2-34T...

  • Page 47: Netvanta 4305 (Ac) And Netvanta 4430

     To comply with GR-1089-CORE, Issue 3, this equipment MUST only be installed in a DC-C (common) bonding and grounding environment. It may not be utilized in a DC-I (isolated) bonding and grounding environment. 61200890E2-34T Copyright © 2019 ADTRAN, Inc.

  • Page 48: Installing Dial Backup And Network Interface Modules

    Slide the NIM with the DIM attached into the NetVanta chassis, continuing with the normal NIM installation (refer to Instructions for Installing the NIMs and Wide NIMs on page 50). Figure 21. Installing DIMs Copyright © 2019 ADTRAN, Inc. 61200890E2-34T...

  • Page 49: Figure 22. Nim And Dim Installation

    Restore power to the unit. ETH 0/2 100-250VAC 50/60Hz WAN-T1 DSX-1 CONSOLE SLOT 3 WIDE MODULE SLOT 2 NET/DBU SLOT 1 NET/DBU ETH 0/1 SLOT 2 NET/DBU WAN-T1 DSX-1 Figure 22. NIM and DIM Installation 61200890E2-34T Copyright © 2019 ADTRAN, Inc.

  • Page 50: Using A Usb Cellular Modem With The Netvanta Usb Wwan Nim

    Refer to the quick start guide that shipped with the NetVanta USB WWAN NIM for instructions on obtaining a cellular account and activating your USB cellular modem. An optional USB Locking Mechanism is available from ADTRAN (P/N 1700643G1) to lock the USB to the NetVanta USB WWAN NIM.

  • Page 51: Installing The Netvanta Vpn Accelerator Card (Included In P/N 4200368L1)

    To avoid damaging the card pins, do not use excessive force. Replace the unit cover, screws, and mounting brackets. Restore power to the unit. Figure 23. NetVanta VPN Accelerator Card Installation 61200890E2-34T Copyright © 2019 ADTRAN, Inc.

  • Page 52: Installing A Sodimm For Expandable Memory

    SODIMMs are intended to be installed only by qualified service personnel. • There are three types of SODIMM memory modules used by ADTRAN: 200-pin DDR1, 200-pin DDR2, and 144-pin DDR2. Although these modules look very similar, they are not interchangeable. Prior to beginning the upgrade process, make sure you have purchased the correct upgrade module for your ADTRAN product.

  • Page 53: Figure 24. Sodimm Installation - Keyed Slots

    NetVanta 4300/4400 Series Unit Installation Figure 24. SODIMM Installation – Keyed Slots Figure 25. SODIMM Installation – Applying Pressure Figure 26. SODIMM Installation – Rotating the Module Downward 61200890E2-34T Copyright © 2019 ADTRAN, Inc.

  • Page 54: Installing A Compactflash Card

    ADTRAN Support Community. For details on the command line interface (CLI), refer to the AOS Command Reference Guide. All other related documents are also available online at http://supportforums.adtran.com. Copyright © 2019 ADTRAN, Inc. 61200890E2-34T...
  • Page 55 NetVanta 4300/4400 Series Unit Installation 61200890E2-34T Copyright © 2019 ADTRAN, Inc.

  • Page 56: Appendix A. Connector Pin Definitions

    Unused Table A-2. 1000Base-T Gigabit Ethernet Port Pinouts Name Description TRD0+ Transmit/Receive Positive TRD0- Transmit/Receive Negative TRD1+ Transmit/Receive Positive TRD2+ Transmit/Receive Positive TRD2- Transmit/Receive Negative TRD1- Transmit/Receive Negative TRD3+ Transmit/Receive Positive TRD3- Transmit/Receive Negative 61200890E2-34T Copyright © 2019 ADTRAN, Inc.

  • Page 57: Table A-3. Sfp Slot Pinouts

    Signal Ground Data Set Ready (output) - Tied to pin 1 — Unused Clear to Send (output) - Tied to pin 1 — Unused Connection directly to an external modem requires a cross-over cable. 61200890E2-34T Copyright © 2019 ADTRAN, Inc.

  • Page 58: Table A-5. Wan-Dds Connector Pinouts

    Unused Table A-7. WAN-E1 Connector Pinouts Name Description Receive data from the network–Ring 1 Receive data from the network–Tip 1 — Unused Transmit data toward the network–Ring Transmit data toward the network–Tip — Unused Copyright © 2019 ADTRAN, Inc. 61200890E2-34T...

  • Page 59: Table A-8. Dsx-1 Connector Pinouts

    Table A-10. WAN-ADSL NIM Connector Pinouts Name Description 1, 2 — Unused ADSL Ring ADSL Tip 5, 6 — Unused Table A-11. WAN-SHDSL Connector Pinouts Name Description Loop 2–Tip Loop 2–Ring — Unused Loop 1–Tip Loop 1–Ring — Unused 61200890E2-34T Copyright © 2019 ADTRAN, Inc.

  • Page 60: Table A-12. Usb Wwan Connector Pinouts

    Table A-13. Serial to Cable Pinouts Serial V.35 X.21 EIA 530 Name TD_A ETC_A TCLK_A RCLK_A RD_A DCD_A DTR_A RTS_A RTS_B (V.11 only) CTS_B (V.11 only) CTS_A DSR_A TM_A TD_B ETC_B TCLK_B RCLK_B RD_B 19-25 Unused Ground Copyright © 2019 ADTRAN, Inc. 61200890E2-34T...

  • Page 61: Table A-14. Analog Modem And Isdn Bri Dbu Connector Pinouts

    Description — Unused Network–Ring Network–Tip — Unused Table A-15. ISDN S/T DBU Connector Pinouts Name Description 1, 2 — Unused Network Receive–Ring 1 Network Transmit–Ring Network Transmit–Tip Network Transmit–Tip 1 7, 8 — Unused 61200890E2-34T Copyright © 2019 ADTRAN, Inc.
