Introduction to the NetVanta 4305
• ADTRAN Operating System (AOS) Command Line Interface (CLI)
• SNMP management
• n-Command network management
• Integrated EIA-232 DCE configuration port (DB-9)
• Optional dial backup (ISDN BRI DIM, ISDN S/T DIM, serial DIM, or analog modem DIM)
• Optional VPN Accelerator Card provides encryption/decryption and security acceleration services
• Front panel LEDs
• Dimensions: 17.22-inch W x 1.72-inch H x 10.99-inch D
• Mountable in a 19-inch rack
• Worldwide auto-ranging AC or DC power supply
• RoHS Compliant (Telecommunications exemption)
This hardware installation guide describes the NetVanta 4305, details basic functionality, gives installation
instructions, and lists hardware specifications. For more information on router configuration for a specific
application, refer to the quick start documents provided on your ADTRAN OS System Documentation CD.
For details on the command line interface, refer to the AOS Command Reference Guide, also on the CD.

Unpack and Inspect the System

Each NetVanta 4305 unit is shipped in its own cardboard shipping carton. Open each carton carefully, and
avoid deep penetration into the carton with sharp objects.
After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damaged in
transit, immediately file a claim with the carrier and contact ADTRAN Customer Service (refer to Repair
and Return on page 8).

Contents of ADTRAN Shipments

NetVanta 4305
Shipments of the NetVanta 4305 include the following items:
• NetVanta 4305 base unit with attached mounting ears
• ADTRAN OS System Documentation CD
• Quick Start Guide
• Warranty card
NetVanta 56K/64K NIM (1200861L1)
Shipments of the 56K/64K NIM include the following items:
• 56K/64K Network Interface Module
• Quick Start Guide
• 6-foot RJ-45 to RJ-45 cable (ADTRAN P/N 3127004)
NetVanta T1/FT1 NIM (1202862L1)
Shipments of the T1/FT1 NIM include the following items:
• T1/FT1 Network Interface Module
• Quick Start Guide
• 15-foot RJ-45 to RJ-45 cable (ADTRAN P/N 3125M008@A)
18
