Summary of Contents for ADTRAN 1200821F1

  • Page 1 NetVanta 3200/3300/3400 Series Routers Hardware Installation Guide 1203860G1 NetVanta 3200 1203870G1 NetVanta 3205 (AC Version) 1203980G1 NetVanta 3205 (DC Version) 1202880E1 NetVanta 3305 1202820G1/F1 NetVanta 3430 1200821E1/F1 NetVanta 3448 1200823G1 NetVanta 3450 1200824G1 NetVanta 3458 1200861L1 NetVanta 56K/64K Network Interface Module 1202862L1 NetVanta T1/FT1 Network Interface Module 1200862L2#NEBS...
  • Page 2 To the Holder of the Manual The contents of this manual are current as of the date of publication. ADTRAN reserves the right to change the contents without prior notice. In no event will ADTRAN be liable for any special, incidental, or consequential damages or for commercial losses even if ADTRAN has been advised thereof as a result of issue of this publication.
  • Page 3 NetVanta 3200/3300/3400 Series Conventions Conventions Notes provide additional useful information. Cautions signify information that could prevent service interruption or damage to the equipment. Warnings provide information that could prevent injury or endangerment to human life. 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 4 Additional safety guidelines, such as Waste Electrical and Electronic Equipment (WEEE), are given in the document NetVanta Safety and Regulatory Information available at https://supportforums.adtran.com. Save These Important Safety Instructions Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 5 Advance notification and the opportunity to maintain uninterrupted service are given. 4. If experiencing difficulty with this equipment, please contact ADTRAN for repair and warranty information. The telephone company may require this equipment to be disconnected from the network until the problem is corrected, or it is certain the equipment is not malfunctioning.
  • Page 6 Denial of Service (DoS) attacks, loss or theft of data, and the unauthorized or illegal use of said equipment. ADTRAN OFFERS NO WARRANTIES, EITHER EXPRESSED OR IMPLIED, REGARDING THE PREVENTION, DETECTION, OR DETERRENCE OF TOLL FRAUD, NETWORKING ATTACKS, OR UNAUTHORIZED, ILLEGAL, OR IMPROPER USE OF ADTRAN EQUIPMENT OR SOFTWARE.
  • Page 7 General Public License (GPL). For a list of third-party software and their licenses, go to  http://www.adtran.com/software/EULA. You can obtain the complete corresponding source code of such software components from ADTRAN for a period of three years after our last shipment of this product by sending a money order or check for $5 to: ADTRAN, Inc, P.O.
  • Page 8: Table Of Contents

    NetVanta SHDSL NIM, Annex A (P/N 1200936E1) ........50 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 9 Appendix A. Connector Pin Definitions ..........79 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 10 Figure 42. NetVanta Octal PoE Upgrade Installation ........78 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 11 ISDN S/T DBU Connector Pinouts ......... . . 85 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 12: Introduction

    For information on switch configuration for a specific application, refer to the configuration guides provided on ADTRAN Support Community. For details on the command line interface (CLI), refer to the Guide. All other related documents are also available online at  Command Reference http://supportforums.adtran.com. 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 13: Physical Descriptions

    • Compatible with ISsec VPN-equipped devices • IP encapsulation over Frame Relay (RFC 1490) • ADTRAN Operating System (AOS) command line interface (CLI) • User-friendly, web-based graphical user interface (GUI) • Standards-based eBGP/iBGP, OSPF, RIP, static routing and bridging protocols •...
  • Page 14: Netvanta 3200 Shipping Contents

    After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damaged in transit, immediately file a claim with the carrier and contact ADTRAN Customer Service (refer to the Support page on the ADTRAN website at http://www.adtran.com/support).
  • Page 15: Netvanta 3200 Front Panel Design

    10Base-T or 100Base-T with a single connector • Auto-negotiation • CSMA/CD • IEEE 802.3 compatibility CONSOLE Interface interface is an EIA-232 serial port (DCE) that provides for local management and CONSOLE configuration (via a DB-9 female connector) 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 16: Netvanta 3205

    Optional ISsec VPN supporting DES/3DES/AES encryption • IP encapsulation over Frame Relay (RFC 1490) • ADTRAN Operating System (AOS) command line interface (CLI) • User-friendly, web-based graphical user interface (GUI) • Standards-based eBGP/iBGP, OSPF, RIP, static routing and bridging protocols •...
  • Page 17: Netvanta 3205 Shipping Contents

    After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damaged in transit, immediately file a claim with the carrier and contact ADTRAN Customer Service (refer to the Support page on the ADTRAN website at http://www.adtran.com/support).
  • Page 18: Netvanta 3205 Front Panel Design

    NetVanta 3205 Rear Panel Interfaces and LEDs SLOT 1 NET/DBU Option Slot option slot supports various NIM plug-in option modules. These option SLOT 1 NET/DBU modules are described in the section Option Modules on page Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 19: Netvanta 3305

    Modular IP access routers for MPLS, Frame Relay, multilink Frame Relay, PPP, MLPPP, PPPoE, ATM, and HDLC networks • Integrated IP router with bridging • IP encapsulation over Frame Relay (RFC 1490) • ADTRAN Operating System (AOS) command line interface (CLI) 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 20 Refer to Using a USB Cellular Modem with the NetVanta USB WWAN NIM on page 72 for details on installing and removing a USB cellular modem from the USB WWAN NIM. Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 21: Netvanta 3305 Shipping Contents

    After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damaged in transit, immediately file a claim with the carrier and contact ADTRAN Customer Service (refer to the Support page on the ADTRAN website at http://www.adtran.com/support).
  • Page 22: Netvanta 3430

    G.703, or ADSL (Annex A or Annex B), SHDSL (Annex A or Annex B), serial, or USB WWAN • Modular IP access routers for MPLS, Frame Relay, multilink Frame Relay, PPP, MLPPP, PPPoE, ATM, and HDLC networks • High-performance processor • Hardware encryption engine embedded • On-board Flash memory Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 23 SODIMM slot • Two integrated 10/100Base-T WAN/LAN ports • ADTRAN Operating System (AOS) command line interface (CLI) • User-friendly, web-based graphical user interface (GUI) • Standards-based BGP, OSPF, RIP, static routing, and bridging protocols •...
  • Page 24: Netvanta 3430 Shipping Contents

    After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damaged in transit, immediately file a claim with the carrier and contact ADTRAN Customer Service (refer to the Support page on the ADTRAN website at http://www.adtran.com/support).
  • Page 25: Netvanta 3430 Front Panel Design

    In addition to the LEDs, this front panel contains a slot for nonvolatile configuration storage and CompactFlash compressed code storage. ADTRAN supports any industry standard 1 GB CompactFlash card. Refer to Installing a CompactFlash Card on page Figure 8. NetVanta 3430 (1202820G1) Front Panel Layout NetVanta 3430 Rear Panel Design The NetVanta 3430 rear panel is shown below with a module installed.
  • Page 26: Netvanta 3448

    Integrated 8-port fully-managed Ethernet switch • Optional Octal PoE upgrade for switch ports to provide (802.3af/Legacy) PoE capability • ADTRAN Operating System (AOS) command line interface (CLI) • User-friendly, web-based graphical user interface (GUI) • Modular IP access routers for MPLS, Frame Relay, multilink Frame Relay, PPP, MLPPP, PPPoE, ATM, and HDLC networks •...
  • Page 27: Netvanta 3448 Shipping Contents

    After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damaged in transit, immediately file a claim with the carrier and contact ADTRAN Customer Service (refer to the Support page on the ADTRAN website at http://www.adtran.com/support).
  • Page 28: Netvanta 3448 Front Panel Design

    37. In addition to the LEDs, this front panel contains a slot for nonvolatile configuration CompactFlash storage and compressed code storage. ADTRAN supports any industry standard 1 GB CompactFlash card. Refer to Installing a CompactFlash Card on page Figure 10. NetVanta 3448 Front Panel Layout Copyright ©...
  • Page 29: Netvanta 3448 Rear Panel Design

    Supplying Power to the Unit on page 64 for connection details. NetVanta 3450 The NetVanta 3450 is a high-performance, modular IP access router designed for cost-effective branch office connectivity over MPLS, Frame Relay, multilink Frame Relay, PPP, MLPPP, or Ethernet networks. 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 30: Netvanta 3450 Features And Specifications

    Expandable memory storage via a CompactFlash card slot on the front panel • Two integrated 10/100Base-T WAN/LAN ports • ADTRAN Operating System (AOS) command line interface (CLI) • User-friendly, web-based graphical user interface (GUI) • Standards-based BGP, OSPF, RIP, static routing, and bridging protocols •...
  • Page 31: Netvanta 3450 Shipping Contents

    After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damaged in transit, immediately file a claim with the carrier and contact ADTRAN Customer Service (refer to the Support page on the ADTRAN website at http://www.adtran.com/support).
  • Page 32: Netvanta 3450 Front Panel Design

    CompactFlash The front panel contains a slot for nonvolatile configuration storage and compressed code CompactFlash storage. ADTRAN supports any industry standard 1 GB CompactFlash card. Refer to Installing a CompactFlash Card on page NetVanta 3450 Rear Panel Design The NetVanta 3450 rear panel is shown below with a module installed.
  • Page 33: Netvanta 3458

    Expandable memory storage via a CompactFlash card slot on the front panel • Two integrated 10/100Base-T WAN/LAN ports • ADTRAN Operating System (AOS) command line interface (CLI) • User-friendly, web-based graphical user interface (GUI) • Standards-based BGP, OSPF, RIP, static routing, and bridging protocols •...
  • Page 34: Netvanta 3458 Shipping Contents

    After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damaged in transit, immediately file a claim with the carrier and contact ADTRAN Customer Service (refer to the Support page on the ADTRAN website at http://www.adtran.com/support).
  • Page 35: Netvanta 3458 Front Panel Design

    Connection directly to an external modem requires a cross-over cable. CompactFlash The front panel contains a slot for nonvolatile configuration storage and compressed code CompactFlash storage. ADTRAN supports any industry standard 1 GB CompactFlash card. Refer to Installing a CompactFlash Card on page 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 36: Netvanta 3458 Rear Panel Design

    IEEE 802.3 compatibility Power Connection All of the 1U-high products have universal power supplies and are shipped with the appropriate cable. Please refer to Supplying Power to the Unit on page 64 for connection details. Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 37: Netvanta 3000 Series Front Panel Leds

    (not present on all Green (solid) The port is enabled and the link is up. units) Amber (flashing) The port has activity (transmit or receive). VPN No encrypted traffic. (not present on all Encrypted traffic present. units) 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 38: Option Modules

    Refer to Using a USB Cellular Modem with the NetVanta USB WWAN NIM on page 72 for details on installing and removing a USB cellular modem from the USB WWAN NIM. Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 39: Option Module Shipping Contents

    Shipments of the Dual T1 NIM include the following items: • Dual T1 Network Interface Module • Quick start guide • Two 15-foot RJ-45 to RJ-45 cable (ADTRAN P/N 3125M008@A) NetVanta E1/FE1 NIM (1200868E1) Shipments of the E1/FE1 NIM include the following items: • E1/FE1 Network Interface Module •...
  • Page 40 • Serial Network Interface Module • Quick start guide • 15-foot RJ-45 to RJ-45 cable (ADTRAN P/N 3125M008@A) NetVanta SHDSL NIM, Annex A (1200936E1) Shipments of the SHDSL NIM, Annex A, include the following items: • SHDSL Network Interface Module •...
  • Page 41 • Quick start guide • 7-foot RJ-45 to RJ-11 cable (ADTRAN P/N 3125M007@A) Option modules are intended to be serviced by qualified service personnel only. System bundles are shipped with a base unit, a network interface module, and other appropriate contents based on the system-level solution ordered.
  • Page 42: Network Interface Modules

    Clock Source • Storage Temperature: -20°C to 70°C • Network Relative Humidity: Up to 95 percent,  • • Internal noncondensing Diagnostics Physical • CSU and DSU Loopbacks • Dimensions: 2.75-inch W x 4.25-inch D Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 43: Netvanta T1/Ft1 Nim (P/N 1202862L1)

    Operating Temperature: 0°C to 50°C • Storage Temperature: -20°C to 70°C Clock Source Relative Humidity: Up to 95 percent,  • Network • • Internal noncondensing Physical • Dimensions: 2.75-inch W x 4.25-inch D 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 44: Netvanta T1/Ft1 Nebs Nim (P/N 1200862L2#Nebs)

    Clock Source • Operating Temperature: 0°C to 50°C • Network • Storage Temperature: -20°C to 70°C • Internal Relative Humidity: Up to 95 percent  • noncondensing Physical • Dimensions: 2.75-inch W x 4.25-inch D Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 45: Netvanta T1/Ft1 + Dsx-1 Nim (P/N 1202863L1)

    Line Codes: AMI, B8ZS noncondensing • DSX-1 Interface to PBX • Framing: D4 (SF) or ESF Physical • Dimensions: 2.75-inch W x 4.25-inch D • Line Length: 0 to 655 feet and -7.5 dB • Connector: RJ-48C 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 46: Netvanta Dual T1 Nim (P/N1200872L1/1202872L1)

    The 1200872L1 Dual T1 module supports the analog modem (1200864L1), ISDN BRI (1200865L1), and ISDN S/T (1200875L1) DIMs for dial backup applications. The 1202872L1 Dual T1 module supports only the analog modem (1200864L1) DIM for dial backup applications. Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 47: Netvanta E1/Fe1 Nim (P/N 1200868E1)

    • Network • Internal Environmental • Operating Temperature: 0°C to 50°C • Storage Temperature: -20°C to 70°C • Relative Humidity: Up to 95 percent, noncondensing Physical • Dimensions: 2.75-inch W x 4.25-inch D 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 48: Netvanta E1/Fe1 + G.703 Nim (P/N 1200878E1)

    Storage Temperature: -20°C to 70°C • Capacity: 1 to 31 timeslots • Relative Humidity: Up to 95 percent, • Connector: RJ-48C noncondensing Clock Source Physical • Network • Dimensions: 2.75-inch W x 4.25-inch D • Internal • Through Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 49: Netvanta Serial Nim (P/N 1200866E1)

    23) can be configured by the user as a V.35, X.21 (V.11), or EIA 530 interface. This module supports rates up to a maximum of 10 Mbps. An additional V.35 (ADTRAN P/N 1200873L1), X.21 (ADTRAN P/N 1200874L1), or EIA 530 (ADTRAN P/N 1200883L1) cable is required (see Caution below). See...
  • Page 50: Netvanta Shdsl Nim, Annex A (P/N 1200936E1)

    • Storage Temperature: -20°C to 70°C Clock Source • CPE Operating Mode: Network • Relative Humidity: Up to 95 percent, • CO Operating Mode: Internal noncondensing Physical • Dimensions: 2.75-inch W x 4.25-inch D Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 51: Netvanta Shdsl Nim, Annex B (P/N 1200937E1)

    Clock Source • CPE Operating Mode: Network • Storage Temperature: -20°C to 70°C • CO Operating Mode: Internal • Relative Humidity: Up to 95 percent, noncondensing Physical • Dimensions: 2.75-inch W x 4.25-inch D 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 52: Netvanta Adsl Nim, Annex A (P/N 1202869E1)

    ATM Forum UNI 3.1/4.0 PVC • Relative Humidity: Up to 95 percent, • ATM class of service (UBR) noncondensing • ATM F5 OAM Physical • Up to 16 virtual circuits • Dimensions: 2.75-inch W x 4.25-inch D Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 53: Netvanta Adsl Nim, Annex B (P/N 1202889E1)

    Storage Temperature: -20°C to 70°C • ATM class of service (UBR) • Relative Humidity: Up to 95 percent, • ATM F5 OAM noncondensing • Up to 16 virtual circuits Physical • Dimensions: 2.75-inch W x 4.25-inch D 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 54: Netvanta Usb Wwan Nim (P/N 1702803F1)

    • FCC Part 15 Class A • EN 55022 Class A Physical • Dimensions: 2.75-inch W x 4.25-inch D • EN 55024 • EN/IEC 60950-1 • UL/CUL 60950-1 • AS/NZS 60950.1 • RoHS compliant Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 55: Dial Backup Interface Modules

    • Dimensions: 2.5-inch W x 3.75-inch D  The Analog Modem DIM can be used in two different modes:  1. Backup interface for a primary connection. 2. CONSOLE port for remote dial-in access. 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 56: Netvanta Isdn Bri Dim (P/N 1200865L1)

    ACTA/FCC Part 68 • IC CS-03 Environmental • Operating Temperature: 0°C to 50°C • Storage Temperature: -20°C to 70°C • Relative Humidity: Up to 95 percent, noncondensing Physical • Dimensions: 2.5-inch W x 3.75-inch D Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 57: Netvanta Isdn S/T Dim (P/N 1200875L1)

    EN/IEC 60950-1 • AS/NZS 60950.1 Environmental • Operating Temperature: 0°C to 50°C • Storage Temperature: -20°C to 70°C • Relative Humidity: Up to 95 percent, noncondensing Physical • Dimensions: 2.5-inch W x 3.75-inch D 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 58: Unit Installation

    UL/IEC 60950-1. • PoE cables are intended for intrabuilding use only. Connecting an ADTRAN PoE unit directly to PoE cables that run outside the building in which the unit is housed will void the user's warranty and could create a fire or shock hazard.
  • Page 59: Mounting Options

    • Reliable grounding of rack-mounted equipment should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuit (e.g., use of power strips). 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 60: Wall Mounting Netvanta 3200/3300/3400 Series

    Do not attach the power cord to the building surface or run it through walls, ceilings, floors, or openings in the building structure. • The socket-outlet must be installed near the equipment and must be easily accessible. Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 61: Figure 29. Wall Mounting The Netvanta 3200

    Slide the keyed insets on the bottom of the unit’s chassis securely onto the screws. Proceed to the steps given in Supplying Power to the Unit on page Figure 29. Wall Mounting the NetVanta 3200 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 62: Figure 30. Repositioning The Mounting Bracket For Wall Mounting The Netvanta 3205/3305

    See Figure Proceed to the steps given in Supplying Power to the Unit on page Figure 30. Repositioning the Mounting Bracket for Wall Mounting the NetVanta 3205/3305 Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 63: Figure 31. Wall Mounting The Netvanta 3430/Netvanta 3448

    Once the unit is hanging, screw the wallmount bracket securely to the wall using a #6 PAN head screw (1.5-inch or greater in length). Proceed to the steps given in Supplying Power to the Unit on page Figure 31. Wall Mounting the NetVanta 3430/NetVanta 3448 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 64: Supplying Power To The Unit

    NetVanta is ready to be powered. To power the unit, ensure that the unit is properly connected to an appropriate power source (as outlined in the sections that follow). Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 65: Powering The Netvanta 3200

    Release the sheath so that it covers the metal connector. This ensures that the connector will not become disengaged during use. Figure 33. NetVanta 3200 Power Connector 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 66: Powering The Netvanta 3205 (Ac), Netvanta 3305, Netvanta 3430, Netvanta 3448, Netvanta 3450, And Netvanta 3458

    The NetVanta PoE Power Supply should be installed in a restricted access location as described in UL 60950-1. Under full load, the NetVanta PoE Power Supply may be hot to the touch. Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 67: Powering The Netvanta 3205 (Dc)

    This interface is designed for use as an intra-building interface only. The addition of primary protectors is not sufficient protection in order to connect this interface metallically to OSP wiring. 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 68: Figure 34. Netvanta 3205 Dc Power Connection

    Ground Ground Ground 24/-48V , 1A 24/-48V , 1A +24 VDC -48 VDC AC In AC In Power Power Supply Supply To Earth To Earth Ground Ground Figure 34. NetVanta 3205 DC Power Connection Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 69: Installing Dial Backup And Network Interface Modules

    Always remove power from the unit prior to removing or installing a module. • Improper installation could result in damage to the modules. • Option slot cover plates should remain in place until a module is installed. 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 70: Figure 35. Installing Dims

    Secure the DIM to the NIM using the screws and standoff posts supplied. See Figure Slide the NIM with the DIM attached into the NetVanta chassis, continuing with the normal NIM installation (refer to Instructions for Installing the NIMs below). Figure 35. Installing DIMs Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 71: Figure 36. Nim And Dim Installation

    Slide the option module into the option slot until the module is firmly seated against the chassis. Secure the pins at both edges of the module. Connect the cables to the associated device(s). Restore power to the unit. WAN-T1 DSX-1 Figure 36. NIM and DIM Installation 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 72: Using A Usb Cellular Modem With The Netvanta Usb Wwan Nim

    Refer to the quick start guide that shipped with the NetVanta USB WWAN NIM for instructions on obtaining a cellular account and activating your USB cellular modem. An optional USB Locking Mechanism is available from ADTRAN (P/N 1700643G1) to lock the USB to the NetVanta USB WWAN NIM.
  • Page 73: Installing The Netvanta Vpn Accelerator Card (Included In P/N 4200368L1)

    Gently slide the accelerator card into the PCI slot as shown. The card is keyed to fit into the slot only one way. To avoid damaging the card pins, do not use excessive force. Replace the unit cover, screws, and mounting brackets. Restore power to the unit. Figure 37. NetVanta VPN Accelerator Card Installation 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 74: Installing Sodimm For Expandable Memory

    Follow these instructions to install a SODIMM module. • SODIMMs are intended to be installed only by qualified service personnel. • There are three types of SODIMM memory modules used by ADTRAN: 200-pin DDR1, 200-pin DDR2, and 144-pin DDR2. Although these modules look very similar, they are not interchangeable.
  • Page 75: Figure 38. Sodimm Installation - Keyed Slots

    NetVanta 3200/3300/3400 Series Unit Installation Figure 38. SODIMM Installation – Keyed Slots Figure 39. SODIMM Installation – Applying Pressure Figure 40. SODIMM Installation – Rotating the Module Downward 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 76: Installing A Compactflash Card

    Slide the module into the CompactFlash slot until the card is firmly seated against the chassis. The CompactFlash options will now be available in the GUI and the AOS CLI. Figure 41. CompactFlash Card Installation Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 77: Installing The Octal Poe Upgrade Module

    Place modules in antistatic packing material when transporting or storing. When working on modules, always place them on an approved antistatic mat that is electrically grounded. The NetVanta Octal PoE Upgrade Module is intended to be installed only by qualified service personnel. 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 78: Figure 42. Netvanta Octal Poe Upgrade Installation

    ADTRAN Support Community. For details on the command line interface (CLI), refer to the AOS Command Reference Guide. All other related documents are also available online at http://supportforums.adtran.com. Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 79: Appendix A. Connector Pin Definitions

    Data Carrier Detect (output) Receive Data (output) Transmit Data (input) Data Terminal Ready (input) Signal Ground Data Set Ready (output) Tied to pin 1 — Unused Clear to Send (output) Tied to pin 1 — Unused 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 80: Table A-3. Console Port (Dce) Pinouts For Netvanta 3305

    Name +24 VDC Source -48 VDC Source +24 VDC Ground (GND) Ground (GND) -48 VDC Table A-5. ADSL Connector Pinouts Name Description 1, 2 — Unused ADSL Tip ADSL Ring 5, 6 — Unused Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 81: Table A-6. Wan-Dds Connector Pinouts

    Unused Table A-8. WAN-E1 Connector Pinouts Name Description Receive data from the network–Ring 1 Receive data from the network–Tip 1 — Unused Transmit data toward the network–Ring Transmit data toward the network–Tip — Unused 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 82: Table A-9. Dsx-1 Connector Pinouts

    Unused Receive data from the DTE–Ring 1 Receive data from the DTE–Tip 1 — Unused Table A-11. WAN-SHDSL Connector Pinouts Name Description Loop 2–Tip Loop 2–Ring — Unused Loop 1–Tip Loop 1–Ring — Unused Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 83: Table A-12. Wan-Adsl Connector Pinouts

    Description 1, 2 — Unused ADSL Ring ADSL Tip 5, 6 — Unused Table A-13. USB WWAN Connector Pinouts Name Description Vbus Provides 5 VDC power up to 1000 mA Data Data Ground Ground 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.
  • Page 84: Table A-14. Serial To Cable Connector Pinouts

    Table A-14. Serial to Cable Connector Pinouts Serial V.35 X.21 EIA 530 Name TD_A ETC_A TCLK_A RCLK_A RD_A DCD_A DTR_A RTS_A RTS_B (V.11 only) CTS_B (V.11 only) CTS_A DSR_A TM_A TD_B ETC_B TCLK_B RCLK_B RD_B 19-25 Unused Ground Copyright © 2019 ADTRAN, Inc. 61200860L1-34AE...
  • Page 85: Table A-15. Analog Modem And Isdn Bri Dbu Connector Pinouts

    Description — Unused Network–Ring Network–Tip — Unused Table A-16. ISDN S/T DBU Connector Pinouts Name Description 1, 2 — Unused Network Receive–Ring 1 Network Transmit–Ring Network Transmit–Tip Network Transmit–Tip 1 7, 8 — Unused 61200860L1-34AE Copyright © 2019 ADTRAN, Inc.

Table of Contents
