NetVanta 4305 Hardware Installation Guide
Table A-6. DSX-1 Connector Pinouts
Pin
Name
1
R
2
T
3
—
4
R1
5
T1
6-8
—
Table A-7. G.703 Connector Pinouts
Pin
Name
1
R
2
T
3
—
4
R1
5
T1
6-8
—
Table A-8. WAN-ADSL NIM Connector Pinouts
Pin
Name
1, 2
—
3
R
4
T
5, 6
—
61200890L1-34H
Description
Transmit data toward the DTE–Ring
Transmit data toward the DTE–Tip
Unused
Receive data from the DTE–Ring 1
Receive data from the DTE–Tip 1
Unused
Description
Transmit data toward the DTE–Ring
Transmit data toward the DTE–Tip
Unused
Receive data from the DTE–Ring 1
Receive data from the DTE–Tip 1
Unused
Description
Unused
ADSL Ring
ADSL Tip
Unused
Copyright © 2006 ADTRAN, Inc.
Appendix A. Connector Pin Definitions
51
