4. UNIT INSTALLATION
The instructions and guidelines provided in this section cover hardware installation topics, such
as tabletop, wall, and rack mounting and powering the units. These instructions are presented as
follows:
•
Mounting Options on page 17
•
Supplying Power to the Unit on page 20
•
Installing SFP Modules in the Unit on page 21
For information on router configuration for a specific application, refer to the configuration guides
provided on the ADTRAN Support
to the AOS Command Reference
https://supportcommunity.adtran.com.
• To prevent electrical shock, do not install equipment in a wet location or
during a lightning storm.
• Pour prévenir les chocs électriques, n'installez pas d'équipement dans un
endroit humide ou lors d'un orage.
• The NetVanta 3148/4148 Series is intended to be installed, maintained, and
serviced by qualified service personnel only and should be installed in a
restricted access location.
• The product is intended for indoor use only. Ethernet, PoE cables, and attached
equipment are intended for use within the same building with equipotential
bonding, and not intended to be placed in separate buildings or structures.
Failure to deploy as described could result in permanent damage from lightning
or other electrical events and voids the warranty. If it is necessary to connect the
ports to remote outdoor equipment or between structures then add an
appropriate protection device per the following:
•ADTRAN's Ethernet Port Protection Device (EPPD) (P/N 1700502G1) must
be connected between the unit and the outside plant cable. Use of any
Ethernet protector other than ADTRAN's for this purpose will void the user's
warranty.
•ADTRAN's NetVanta PoE Protector/Injector (P/N 1702595F15) must be
connected between the unit and the outside plant cable. Use of any PoE
protector other than ADTRAN's for this purpose will void the user's warranty.
