NetVanta 4305 Hardware Installation Guide
Reviewing the Rear Panel Design
Figure 2 shows the NetVanta 4305 (AC) rear panel and Figure 3 shows the NetVanta 4305 (DC) rear panel.
The chassis are shown with the T1/FT1 + DSX-1 NIM installed.
CONSOLE
Rear Panel Interfaces and LEDs
10/100BaseT Ethernet Interface and Activity LEDs
The Ethernet ports (
flashes when data traffic is being sent or received on the Ethernet port. The green link LED is on when
the router has a good connection to the LAN. See Table A-1 on page 49 for the Ethernet port pinouts.
The Ethernet port provides the following:
•
10BaseT or 100BaseT with a single connector
•
Auto-negotiation
•
CSMA/CD
•
IEEE 802.3 compatibility
CONSOLE Interface
The
interface is an EIA-232 serial port (DCE) which provides for local management and
CONSOLE
configuration (via a DB-9 female connector). Table A-2 on page 49 shows the
Connection directly to an external modem requires a cross-over cable.
NET/DBU Option Slots
The
SLOT 1 NET/DBU
These option modules are described in the section Option Modules on page 24.
Power Supply
The NetVanta 4305 (AC) has a worldwide auto-ranging AC power supply with an IEC connector. The
appropriate three-prong cable is included in the shipment. A 4-position terminal block is included in
the shipment for connection of the NetVanta 4305 (DC) to a 24 or 48 VDC power source. Please refer
to Supplying Power to the Unit on page 44 for connection details.
61200890L1-34H
SLOT 3 WIDE MODULE
Figure 2. NetVanta 4305 (AC) Rear Panel Layout
Figure 3. NetVanta 4305 (DC) Rear Panel Layout
) are RJ-48C connectors with LEDs. The yellow activity LED
ETH 0/1, ETH 0/2
and
SLOT 2 NET/DBU
Copyright © 2006 ADTRAN, Inc.
WAN-T1
DSX-1
DBU
WAN-T1
DSX-1
DBU
SLOT 2 NET/DBU
option slots support various NIM plug-in modules.
Physical Description
ETH 0/2
100-250VAC
WAN-T1
DSX-1
DBU
SLOT 1 NET/DBU
ETH 0/1
port pinouts.
CONSOLE
50/60Hz
23
