Physical Description
LED
LAN 1/LAN 2
Green (solid)
LNK
Yellow (solid)
WIDE SLOT 1
Off
STATUS
Green (solid)
Red (solid)
WIDE SLOT 1
Green (flashing)
ACTIVITY
Off
WIDE SLOT 1
Off
TEST
Yellow (solid)
22
Table 1. NetVanta 4305 LEDs (Continued)
Color
The 10BaseT Ethernet link is up.
The 100BaseT Ethernet link is up.
The card is not installed.
The card is recognized by the system.
An alarm condition exists with the card.
There is data activity on the card (e.g., for the Octal T1 module,
this indicates TD/RD data).
There is no activity on card.
There is no test running.
The card is in test mode.
