Displaying the
Server Table
Top-Level Menu
system
interface
ethernet
route
fddi
display
atm server
static
bridge forwarding
remove
ip
rip
flush
ipx sap
statistics
appletalk
snmp
analyzer
IPX forwarding is enabled, RIP is active, SAP is active,
script
RIP Trig enabled, SAP Trig enabled
logout
Interface
Defining a Static
Server
Top-Level Menu
system
interface
ethernet
route
fddi display
atm server
static
bridge
forwarding
remove
ip
rip
flush
sap
ipx
statistics
appletalk
snmp
analyzer
script
logout
You can display the system server table to determine which servers are
learned and whether they are operational.
To display the server table, from the top level of the Administration
Console, enter:
ipx server display
This example shows information about known servers, IPX forwarding,
RIP, and SAP.
Name Type
2 GB201 39b 8c141bfe
2 GB3COM2 39b af0bc60f
Before you define static servers on the system, you must define at least
one IPX interface. See "Defining an Interface" on page 12-3 for more
details. Static servers remain in the table until you remove them or until
you remove the corresponding interface. Static servers take precedence
over dynamically learned servers to the same destination. You can have a
maximum of 8 static servers. To define a static server:
1 From the top level of the Administration Console, enter:
ipx server static
2 Enter the interface number of the server.
3 Enter the service type of the server.
4 Enter the service name of the server.
5 Enter the IPX network address of the server.
6 Enter the socket value of the server.
7 Enter the node address of the server.
8 Enter the number of hops to the server.
Example:
Enter Interface number: 1
Enter service type: 4
Enter service name: gb201
Enter IPX address: 0x8c14a238
Enter socket: 0x8059
Enter node address: 00-00-2e-f3-56-01
Enter hops: 2
Network
08-00-02-04-80-b6
00-00-00-00-00-01
Administering Servers
Node Socket Hops
8059 4
85fa 4
12-7
Age
73
85
