Displaying IPX
Interfaces
Top-Level Menu
system
ethernet interface
fddi
route
display
atm
server
define
bridge forwarding
modify
ip
rip
remove
ipx sap
statistics
appletalk
snmp
analyzer
script
logout
Defining an Interface
Top-Level Menu
system
ethernet interface
fddi display
route
atm
server define
bridge
forwarding
modify
ip
rip
remove
sap
ipx
statistics
appletalk
snmp
analyzer
script
logout
Use this command to display a table that shows all IPX interfaces and
their parameter settings currently configured for the system.
To display IPX interface information, from the top level of the
Administration Console, enter:
ipx interface display
Example with IPX interface, IPX forwarding, RIP, and SAP information:
IPX forwarding is enabled, RIP is active, SAP is active,
RIP Trig enabled, SAP Trig enabled
Index IPX address
1 45469f30
2 5d41a110
3 6d321a22
When you define an interface, you define the interface's IPX address,
cost, format, and any associated IPX VLAN index.
Before you define the IPX interface to associate with a VLAN, define the
IPX VLAN. See Chapter 9, "Administering VLANs."
To define an IPX interface:
1 From the top level of the Administration Console, enter:
ipx interface define
You are prompted for the interface parameters. Press Return to accept
the existing values, shown in brackets.
2 Enter the IPX network address of the interface.
3 Enter the cost of the interface.
4 Enter the frame format of the interface.
5 Enter the index of the IPX VLAN that is associated with this interface.
Example:
Enter IPX Address: 0x45469f30
Enter Cost [1]: 1
Enter Frame Format (Ethernet II, 802.2, Raw 802.3, SNAP): 802.2
IPX VLANs:
Index Ports
3 1-8
4 9-12
Select VLAN index: 3
Administering Interfaces
Cost Format
1 802.2
1 802.2
1 802.2
12-3
State VLAN index
Up 2
Up 1
Up 4
