The following sample shows a summary display for several VLANs:
- VLAN summary
Index Protocol
1 default
2
Index Name
1
2 150.14
The following sample shows a detailed display for these VLANs:
- VLAN detail
Index Protocol
1 default
2 IP
Index Name
1
2 150.14
Index inPackets
1
2 453
Table 9-1 describes these statistics.
Table 9-1 Field Attributes for VLAN Information
Field
Description
Index A system-assigned index that identifies a VLAN
Protocol The protocol suite of the VLAN
Identifier A unique, user-defined (4-byte) integer for use by global
management operations
Ports The numbers of the ports that are assigned to the VLAN
Name A 16-byte character string that identifies the members of the
VLAN
Layer 3 Optional parameters (consisting of IP subnetwork and mask) that
are used to set up flood domains for overlapping IP VLAN
subnetworks
inPackets The number of flooded packets that are received on the VLAN
inBytes The number of flooded bytes that are received on the VLAN
outPackets The number of flooded packets that are transmitted over the
VLAN
outBytes The number of flooded bytes that are transmitted over the VLAN
Identifier
0
IP 2
Layer 3
none
158.101.150.0
Identifier
0
2
Layer 3
none
158.101.150.0 255.255.255.0
inBytes outPackets
54 7654
181028
Ports
1-18
3
255.255.255.0
Ports
1-18
3
outBytes
54 6897
453 181028
