12-14 C 12: A
HAPTER DMINISTERING
Displaying IPX
Forwarding Statistics
Top-Level Menu
system
interface
ethernet
route summary
fddi
server rip
atm
forwarding sap
bridge
rip
ip
forwarding
sap
ipx
statistics
appletalk
snmp
analyzer
script
logout
Received
1335653
Hdr Errors
No Routes
NetBIOS Rx
Host Rx
Table 12-4 IPX Forwarding Statistics
Field Description
Received Number of IPX forwarding packets that were received
Transmitted Number of IPX forwarding packets that were transmitted
Forwarded Number of IPX packets that were forwarded by the IPX router
Hdr Errors Number of IPX packets that were dropped because of IPX Network layer header errors
Hop Count Errors Number of IPX packets that were dropped because of exceeded maximum transport control
Addr Errors Number of IPX packet that were dropped because of IPX Address errors in network layer
header
No Routes Number of IPX packets that were dropped because the IPX route is unknown
Misc Errors Number of multicasts that the system attempted to forward
NetBIOS Rx Number of IPX NetBIOS packets that were received
NetBIOS Tx Number of IPX NetBIOS packets that were transmitted
NetBIOS Max Hops Number of IPX NetBIOS packets that exceeded the transport control maximum
Host Rx Number of IPX packets that were delivered to the IPX host's RIP and SAP applications
Host Tx Number of IPX packets that were transmitted from the IPX host's RIP and SAP applications
IPX R
OUTING
To display IPX forwarding statistics, from the top level of the
Administration Console, enter:
ipx statistics forwarding
This example shows IPX forwarding statistics:
13758
2
150604
0
Table 12-4 describes the IPX forwarding statistics.
Transmitted
565105
Hop Count Errors
0
Misc Errors
411
NetBIOS Tx
125781
Host Tx
0
Forwarded
0
Addr Errors
13758
NetBIOS Max Hops
0
