Displaying The Routing Table; Defining A Static Route - 3Com CoreBuilder 2500 User Manual

Displaying the
Routing Table
Top-Level Menu
system
ethernet
interface
fddi
route
display
atm
arp
static
bridge
atmArpServer
remove
ip
multicast
flush
ipx
udpHelper
default
appletalk routing
noDefault
snmp icmpRouterDiscovery
analyzer
ospf
script rip
logout
ping
statistics
IP routing is enabled, ICMP router discovery is disabled
Destination
Default Route
9.0.0.0
10.0.0.0
89.0.0.0
129.213.0.0
Defining a Static
Route
Top-Level Menu
system
ethernet interface
fddi
route
display
atm
arp
static
bridge
atmArpServer
remove
ip
multicast
flush
ipx udpHelper
default
appletalk routing
noDefault
snmp
icmpRouterDiscovery
analyzer ospf
script rip
logout
ping
statistics
You display a module's routing table to determine the routes that are
configured and whether they are operational.
To display the contents of the routing table, from the top level of the
Administration Console, enter:
ip route display
This example shows part of a routing table:
Subnet mask
--
255.0.0.0
255.0.0.0
255.0.0.0
255.255.0.0
Depending on the system configuration, the table displays IP, RIP, and
OSPF routing configurations and destination default routes.
Before you define static routes, define at least one IP interface. (See
"Defining an IP VLAN Interface" earlier in this chapter for more
information.) Static routes remain in the table until you remove them or
until you remove the corresponding interface. Static routes take
precedence over dynamically learned routes to the same destination.
Static routes are not included in the system's periodic RIP updates. They
are included in OSPF updates as type 1 externals.
To define a static route:
1 From the top level of the Administration Console, enter:
ip route static
2 Enter the destination IP address of the route.
3 Enter the subnet mask of the route.
4 Enter the gateway IP address of the route.
Administering Routes
Metric Gateway
3 158.101.112.254
3 158.101.112.254
3 158.101.112.254
3 158.101.112.254
3 158.101.112.254
10-9
Status
Learned RIP
Learned RIP
Learned RIP
Learned RIP
Learned RIP
