Pressing 2 while viewing the Program Check screen will display a screen similar to the
following:
@@@ZONES@NO@INPUT
05@07@09@10@11@1M001
The Zone No Input screen allows the programmer to view the zones which have not been
programmed to at least one input device (not including general alarm Zone 00). The
example in the preceding screen indicates that Zones 05, 07, 09, 10 and 11 have been
programmed to an addressable module (control module in this example) with an address
of 001 on loop 1 but have not been programmed to any input devices. Use the up and
down arrow keys to view all the zones without input assignments.
Pressing 3 while viewing Program Check screen will cause a screen similar to the
following to be displayed:
@@@ZONES@NO@OUTPUT
05@07@09@10@11@1D001
The Zone No Output feature allows the programmer to view the zones which have not
been programmed to at least one output device (not including general alarm Zone 00). The
example in the preceding screen indicates that Zones 05, 07, 09, 10 and 11 have been
programmed to an addressable detector with an address of 001 on loop 1 but have not been
programmed to any output devices. Use the up and down arrow keys to view all the zones
without output assignments.
