Brake Lines

13
3
9
10
2
1. Brake line − rear
2. Brake line − front
3. Brake line − rear
4. Cap screw (2)
5. Flange head screw
6. R−Clamp
When performing service work on the Multi Pro brake
lines, make sure to clean brake components before dis-
assembly. Record routing of brake lines and location of
cable ties and clamps before removing brake lines from
machine. Reinstall brake lines with all cable ties and
clamps as recorded. Make sure that the brake lines do
not contact moving components during machine opera-
tion.
Multi Pro 1750
11
12
14
15
16
7
6
4
5
1
Figure 10
7. Pressure switch
8. Tie clip (2)
9. Brake hold valve
10. Hex washer head (2)
11. Master cylinder
12. Flange nut (2)
Page 8 − 17
17
8
4
RIGHT
FRONT
13. Flange head screw (2)
14. Clevis pin
15. Hair pin
16. Lock nut
17. Cable tie
Chassis
