Suction Tube and Strainer

1
RIGHT
FRONT
1. Filter basket
2. Tee
3. O−Ring (4)
4. Straight fitting
5. Hose clamp
6. Hose (from agitation bypass valve)
7. Straight fitting
8. Hose clamp
9. Hose (to spray pump)
Spray System
8
7
3
2
9
10
11
12
13
14
15
16
18
20
21
22
23
24
23
25
27
Figure 28
10. Fork (4)
11. Connector
12. Filter adapter
13. O−Ring
14. Screen vane
15. Strainer screen
16. Suction filter body
17. Fork
18. O−Ring
Page 6 − 42
3 4
5
6
3
10
17
19
26
19. Spring pin (2)
20. Straight fitting
21. Gasket
22. Filter bulkhead nut
23. Hose clamp (2)
24. Hose
25. Suction tube
26. Suction foot
27. Screw
Multi Pro 1750
