System Specifications - GE AKTA GO Operating Instructions Manual

9 Reference information

9.1 System specifications

9.1

System specifications

Technical specifications
Parameter
System configuration
Flow rate range
Pressure range
Control system
Connection between PC and instrument
Dimensions (width × height × depth)
Weight (excluding computer, columns, buffer
bottles)
Supply voltage
Maximum voltage fluctuation
Frequency
Power consumption
Enclosure protective class
Acoustic noise level
1
ÄKTA go can deliver 300 VA.
2
ÄKTA go equipped with all options consume 150 W.
Battery information
The instrument version with Real-Time Unit contains a lithium backup battery. The battery
cannot be replaced by the user.
102
Data
Benchtop system, external computer
0.01 to 25 mL/min
0 to 5 MPa (0 to 50 bar)
UNICORN 7.4 or later version
Ethernet
335 × 482 × 464 mm
(depth without tray 451 mm, depth without mod-
ules 380 mm)
27 kg
100 to 240 V~ autorange
± 10% from the nominal voltage
50/60 Hz
1
Rated max 300 VA
Max with all options 150 W
Typical 100 W
Power-save < 20 W
IP 21
< 60 dB(A)
ÄKTA go Operating Instructions 29360951 AC
2
