iWave iW-RainboW-G22D Hardware User's Manual page 23

RZ/G1E SODIMM Development Platform Hardware User Guide
Pin SODIMM Edge Connector Signal
No. Name
112 SD0_DAT2(GP6_4)
113 GND
114 SD0_DAT3(GP6_5)
115 I2C5_SDA(GP0_15)
116 I2C5_SCL(GP0_14)
117 SCIF4_RXD(GP0_5)
118 SCIF4_TXD(GP0_6)
119 ETH_CRS_DV/VI1_CLK(GP5_11)¹
120 ETH_INT/EXP_VI1_DATA7(GP5_1
9)¹
121 VI1_VSYNC(GP5_23)
122 GPIO(GP1_22)
123 VI1_HSYNC(GP5_22)
124 VIN_3V3
125 TPUTO0_C(GP1_18/MD8)
126 ETH_TXD0/VI1_CLKENB(GP5_20)¹
127 NC
iWave Systems Technologies Pvt. Ltd.
Signal Type/
Termination
IO, 3.3V CMOS
Power
IO, 3.3V CMOS
IO, 3.3V OD
I, 3.3V OD
O, 3.3V CMOS
I, 3.3V CMOS
O, 3.3V CMOS
O, 3.3V CMOS
O, 3.3V CMOS
I, 3.3V CMOS
O, 3.3V CMOS
O, 3.3V Power
I, 3.3V CMOS
I, 3.3V CMOS
-
Description
SD0 Data2.
This pin is connected to Micro SD connector
J19.
Ground.
SD0 Data3.
This pin is connected to Micro SD connector
J19.
I2C5 data.
This pin is connected to I2C devices.
I2C5 clock.
This pin is connected to I2C devices.
SCIF4 Interface serial data receiver.
This pin is connected from Serial to USB
converter for Debug console.
SCIF4 Interface serial data transmitter.
This pin is connected to Serial to USB
converter for Debug console.
VIN1 Parallel Camera Clock.
This pin is connected from camera connector
J6.
VIN1 Parallel Camera Data7.
This pin is connected from camera connector
J6.
VIN1 Camera Vertical Synchronization.
This pin is connected from camera connector
J6.
Camera Reference Clock.
Note: This pin is optionally connected from
camera connector through resistor and
Default not populated.
VIN1 Camera Horizontal Synchronization.
This pin is connected from camera connector
J6.
Supply Voltage.
Pulse Width Modulation Output.
This pin is connected to Expansion Header J12
Pin 18.
Active high Camera Power Down.
This pin is connected to camera connector J6.
NC in carrier board.
GPIO(GP5_0) signal from RZ/G1E CPU is
available in this pin.
REL1.1
Page 23 of 71
