RZ/G1E SODIMM Development Platform Hardware User Guide
Pin
SODIMM Edge Connector Signal
No.
Name
143
DU0_VSYNC(GP2_28/MD12)
144
DU0_HSYNC(GP2_27/MD11)
145
DU0_DOTCLKOUT0(GP2_25)
146
DU0_DISP(GP2_30/MD10)
147
TPUTO3_C(GP0_21)
148
DU0_DR0(GP2_0)
149
DU0_DR1(GP2_1)
150
DU0_DR2(GP2_2)
151
GND
152
DU0_DR3(GP2_3)
153
DU0_DR4(GP2_4)
154
DU0_DR5(GP2_5)
155
DU0_DR6(GP2_6)
156
DU0_DR7(GP2_7)
157
DU0_DG0(GP2_8)
158
DU0_DG1(GP2_9)
159
DU0_DG2(GP2_10)
160
VIN_3V3
161
DU0_DG3(GP2_11)
162
DU0_DG4(GP2_12)
iWave Systems Technologies Pvt. Ltd.
Signal Type/
Termination
I, 3.3V CMOS
I, 3.3V CMOS
I, 3.3V CMOS
I, 3.3V CMOS
I, 3.3V CMOS
I, 3.3V CMOS
I, 3.3V CMOS
I, 3.3V CMOS
Power
I, 3.3V CMOS
I, 3.3V CMOS
I, 3.3V CMOS
I, 3.3V CMOS
I, 3.3V CMOS
I, 3.3V CMOS
I, 3.3V CMOS
I, 3.3V CMOS
I, 3.3V Power
I, 3.3V CMOS
I, 3.3V CMOS
Description
Parallel LCD VSYNC.
This pin is connected to LCD connector J23.
Parallel LCD HSYNC
This pin is connected to LCD connector J23.
Parallel LCD Clock.
This pin is connected to LCD connector J23.
Parallel LCD Enable.
This pin is connected to LCD connector J23.
Pulse Width Modulation 3 Output.
This pin is connected to LCD connector J23 for
brightness control.
Parallel LCD data 16 (Red data0).
This pin is connected to GPIO header J16 pin
7.
Parallel LCD data 17 (Red data1).
This pin is connected to GPIO header J16 pin
8.
Parallel LCD data 18 (Red data2).
This pin is connected to LCD connector J23.
Ground.
Parallel LCD data 19 (Red data3).
This pin is connected to LCD connector J23.
Parallel LCD data 20 (Red data4).
This pin is connected to LCD connector J23.
Parallel LCD data 21 (Red data5).
This pin is connected to LCD connector J23.
Parallel LCD data 22 (Red data6).
This pin is connected to LCD connector J23.
Parallel LCD data 23 (Red data7).
This pin is connected to LCD connector J23.
Parallel LCD data 8 (Green data0).
This pin is connected to GPIO header J16 pin 5
Parallel LCD data 9 (Green data1).
This pin is connected to GPIO header J16 pin
6.
Parallel LCD data 10 (Green data2).
This pin is connected to LCD connector J23.
Supply Voltage.
Parallel LCD data 11 (Green data3).
This pin is connected to LCD connector J23.
Parallel LCD data 12 (Green data4).
This pin is connected to LCD connector J23.
REL1.1
Page 25 of 71
