RZ/G1E SODIMM Development Platform Hardware User Guide
2.2

RZ/G1E SODIMM Carrier Board Features

RZ/G1E SODIMM carrier board supports the following features to support various interfaces from RZ/G1E SODIMM
SOM Edge connector
Serial Interface Features
•
Debug UART through USB Micro AB Connector
•
DATA UART (HSCIF1) x 1 Port through Header
Communication Features
•
100/1000 Mbps (EtherAVB) Ethernet through RJ45MagJack
•
10/100Mbps Ethernet PHY Transceiver (Optional)
•
USB 2.0 OTG as a device x 1 Port through Micro AB Connector
•
USB 2.0 Host x 2 Ports through USB Type-A Connector
•
SD x 1 Port through Micro SD Connector
•
CAN x 1 Port through Header
Audio/Video Features
•
I2S Audio Codec with 3.5mm Audio IN/OUT jack
•
4.3" RGB LCD Connector with Resistive Touch
•
8-bit Camera x 1 Port
Additional Features
•
Reset Switch
•
20-Pin JTAG Connector
•
RTC Coin Cell Holder
•
RTC Controller (Optional)
20Pin Expansion Header
•
Data UART (HSCIF2) x 1 Port
•
UART (SCIF1, SCIF5) x 2 Ports
•
CAN (CAN1) x 1 Port
•
SPI (MSIOF1) x 1 Port
•
PWM x 1 Port
20Pin GPIO Header
•
SPI (MSIOF2) x 1
•
GPIOs x 12 Nos
