RZ/G1E SODIMM Development Platform Hardware User Guide

3.2.5 DIP Switch

The RZ/G1E HDMI Add-On Module has one General Purpose 4bit DIP Switch (SW1) and connected from RZ/G1E CPU
GPIOs. GPIO status can be changed by changing the switch position High or Low. This DIP Switch (SW1) is physically
located at the top of the board as shown below.
The functionality of Board DIP Switch (SW1) in the RZ/G1E HDMI Add-On Module is explained in the following table.
Warning: For DIP Switch (SW1) of 3
before power is supply make sure that 3
Table 18 DIP Switch
SW1 Bits
1
2
3
4
iWave Systems Technologies Pvt. Ltd.

Figure 25: DIP Switch

rd
bit MD18 pin is Connected from CPU, This may effect for boot sequence So
rd
bit of SW1 is LOW(OFF).
SW1 Bit Name
GP4_7
GP0_1O
GP1_13/MD18
NC
Description
OFF
Low
Low
Low
NA
ON
High
High
High
NA
