iWave iW-RainboW-G22D Hardware User's Manual page 18

RZ/G1E SODIMM Development Platform Hardware User Guide
Pin SODIMM Edge Connector Signal
No. Name
44 NC
45 NC
46 VIN_3V3
47 NC
48 NC
49 NC
50 NC
51 GND
52 NC
53 NC
54 NC
55 NC
56 NC
57 NC
iWave Systems Technologies Pvt. Ltd.
Signal Type/
Termination
IO, 3.3V CMOS
IO, 3.3V CMOS
O, 3.3V Power
-
-
-
IO, 3.3V CMOS
Power
IO, 3.3V CMOS
IO, 3.3V CMOS
IO, 3.3V CMOS
IO, 3.3V CMOS
IO, 3.3V CMOS
IO, 3.3V CMOS
Description
NC.
GPIO(GP0_19) signal from RZ/G1E CPU is
available in this pin.
Note: This pin is connected to second ethernet
jack (J4).
NC.
GPIO(GP1_12) signal from RZ/G1E CPU is
available in this pin.
Note: This pin is connected to second ethernet
jack (J4).
Supply Voltage.
NC in carrier board.
MSIOF1_SYNC(GP0_27) signal from RZ/G1E
CPU is optionally connected to this pin.
NC in carrier board.
GPIO(GP4_0) signal from RZ/G1E CPU is
optionally connected to this pin.
NC.
NC in carrier board.
GPIO(GP1_15) signal from RZ/G1E CPU is
optionally connected to this pin.
Ground.
NC in carrier board.
SCIF2_RXD(GP4_16) signal from RZ/G1E CPU is
optionally connected to this pin.
NC in carrier board.
SCIF2_TXD(GP4_17) signal from RZ/G1E CPU is
optionally connected to this pin.
NC in carrier board.
SCIF2_SCK(GP4_18) signal from RZ/G1E CPU is
optionally connected to this pin.
NC in carrier board.
SCIF3_SCK(GP4_19) signal from RZ/G1E CPU is
optionally connected to this pin.
NC in carrier board.
SCIF3_RXD(GP4_20) signal from RZ/G1E CPU is
optionally connected to this pin.
NC in carrier board.
SCIF3_TXD(GP4_21) signal from RZ/G1E CPU is
optionally connected to this pin.
REL1.1
Page 18 of 71
