iWave iW-RainboW-G22D Hardware User's Manual page 16

Rz/g1e sodimm development platform
Table of Contents

Advertisement

RZ/G1E SODIMM Development Platform Hardware User Guide
Pin
SODIMM Edge Connector Signal
No.
Name
18
NC
19
NC
20
VIN_3V3
21
NC
22
NC
23
NC
24
NC
25
NC
26
NC
27
GND
28
NC
29
NC
30
ETH_SPEED_LED1
31
NC
32
VIN_3V3
iWave Systems Technologies Pvt. Ltd.
Signal Type/
Termination
I, 3.3V OD
IO, 3.3V OD
O, 3.3V Power
IO, 3.3V CMOS
IO, 3.3V CMOS
IO, 3.3V CMOS
IO, 3.3V CMOS
IO, 3.3V CMOS
IO, 3.3V CMOS
Power
IO, 3.3V CMOS
IO, 3.3V CMOS
-
IO, 3.3V CMOS
O, 3.3V Power
Description
NC in carrier board.
I2C3_SCL(GP0_3) signal from RZ/G1E CPU is
available in this pin.
NC in carrier board.
I2C3_SDA(GP0_4) signal from RZ/G1E CPU is
available in this pin.
Supply Voltage.
NC in carrier board.
GPIO(GP0_1) signal from RZ/G1E CPU is
available in this pin.
NC in carrier board.
GPIO(GP0_2) signal from RZ/G1E CPU is
available in this pin.
NC in carrier board.
GPIO(GP0_7) signal from RZ/G1E CPU is
available in this pin.
NC in carrier board.
GPIO(GP5_3) signal from RZ/G1E CPU is
available in this pin.
NC in carrier board.
GPIO(GP1_23) signal from RZ/G1E CPU is
available in this pin.
NC in carrier board.
GPIO(GP1_24) signal from RZ/G1E CPU is
available in this pin.
Ground.
NC in carrier board.
GPIO(GP0_16) signal from RZ/G1E CPU is
available in this pin.
NC in carrier board.
GPIO(GP0_17) signal from RZ/G1E CPU is
available in this pin.
NC.
Note: This pin is connected to second ethernet
jack (J4) LED status pin for 10/100 Ethernet
connection.
NC in carrier board.
GPIO(GP0_0) signal from RZ/G1E CPU is
available in this pin.
Supply Voltage.
REL1.1
Page 16 of 71
