r) Reset
v) Change version control for loading
0) Exit
>>
Note
In BOOT mode, only the LAN1 connector is available.
Accessing the BIOS menu from the console without using the RST button
It is also possible to access the BIOS menu without using the RST button if you have access to the device's local
console. Simply access the BOOT menu and, from there, execute the "rb" command. Below you can see an example
of a H1+/H1+GE in BIOS mode start up:
CFE> rb
Booting from only image (0xb8160000) ...
Code Address: 0x80010000, Entry Address: 0x802f8000
Booting version 10.08.06
Decompression OK!
Entry at 0x802f8000
Closing network.
Disabling Switch ports.
Flushing Receive Buffers...
19 buffers found.
Closing DMA Channels.
Starting program at 0x802f8000
CIT software version: 10.08.06
Current software license: 26 48
S/N: 728/00132
=== INITIAL
a) Set Date and Time
d) Change Licence
f) Disk menu
l) Load from lan
r) Reset
v) Change version control for loading
0) Exit
>>
Note
In BOOT mode, only the LAN1 connector is available.

1.5 Wall mounting

The Teldat H1+/H1+GE router has four holes in its metal underside so it can be mounted on a wall.
Teldat H1+/H1+GE
MENU ===
1 Installing the Router
25
