A.3.4 WLAN connectors (male)
A.3.5 USB connector
USB Type A
A.3.6 FXS connector (optional)
RJ11 FXS
A.3.7 Configuration connector
RJ45 CONFIGURATION
Teldat H1+/H1+GE
PIN
Internal
External
PIN
1
2
3
4
Shell
RJ45 PIN
1
2
3
4
RJ45 PIN
1
2
3
4
5
6
7
8
ANT
RF in/out
GND
USB
VCC
DATA-
DATA+
GND
Shield
CONF
--
Tip
Ring
--
CONF
--
RxD
GND
--
--
GND
TxD
--
Technical Information
