3 Components and Power Supply
The Teldat 4Ge LEDs are shown in Figure 6. The table below contains a description of each:
LEDs table
LED
LAN
PWR
W

3.2 Assembly

3.2.1 Mounting in rack

The Teldat 4Ge cannot be mounted in a rack. However, there are other types of mounting.

3.2.2 Standalone

The Teldat 4Ge can be placed as a standalone device on a flat, stable surface.
Make sure there is enough space around the router for ventilation purposes and that electricity cables can reach it.

3.2.3 Wall mounting

The Teldat 4Ge can be mounted on the wall.
There are two slots on the underside of the device, used to fix it to the wall. You can see this in
page 6.
We recommend the following accessories for wall mounting, valid for solid and Gypsum board (plaster) walls:
• 2 screws: [Coach Screw Head 90 Degrees. 3.5x30].
8
Status
Tricolor
Monochrome green
Tricolor
Description
Green -> connected. Blinking: con-
nection data activity.
Amber -> blinking: auto-test.
Red -> disconnected.
Device ON/OFF. This lights up when
connected to the power source.
Off -> system stopped.
Red -> interface unavailable because
it is installing, not enabled (shutdown)
or due to auto-test failure.
Yellow -> idle.
• Rapid blinking. It has not registered
in the network or the quality is in-
sufficient.
• Slow blinking. GSM connection
(GPRS).
• Steady. WCDMA (UMTS/HSDPA)
connection.
Green -> connected. Blinking: con-
nection data activity.
Underside Panel
Teldat S.A.
on
Teldat 4Ge Router
